High Speed Stripping Machine

Max mechanical speed:250m/min
Max web width:
1300mm
Max unwinding diameter:
600mm
Max rewinding diameter:
450mm
Stripping width:80-1300mm
Tolerance of EPC: 1mm
Overall Dimension:
3150*1950*1460mm
Total power:7kw

Film materials and thin paper

The main motor adopts imported variable frequency speed regulating
Unwinding tension half auto control with brake
Rewinding tension half auto control with magnetic clutch
Automatic meter counting
Slitting of circle knife,even knife
Automatic EPC for unwinding
