* Characteristics:
1. The main motor adopts imported converter to govern in a stepples way.
2. Feeding and discharging are controlled through magnetic powder brake and clutch(Japanese Mitsubishi auto tension controller).
3. Adopt ceramic mesh distributor roller, which is characterized by durability, wear resistance, and corrosion resistance. The doctors can be Used, which is more efficient for reducing the times for changing in order to increase the production efficiency.
4. The printing unit can register in 360 degrees. Each printing unit can independently gear and loosen to have the units continue printing.
5. The printing units are all equipped with a group of infrared dryers respectively.
6. The rolling device is adopted clipping device with air-expansion core shaft.
7. The inking roller can automatically fall off at stoppage and transfer at low speed in order to keep the ink from being dry and solid.
8. The roll feeding, printing, polishing, auto infrared drying, laminating and fast rolling can be processed in one processing. It is characterized by wide application, non-population of printing ink and fast drying, quick printing. So it is an ideal printing machine for the commercial bill to print high-Graded free adhesive trademark.
* Main technical parameters :
-Printing speed : 60m/Minutes
-Be printed color : 5Color
-Web maximum width : 320mm
-The largest printing width : 310mm
-Roll diameter : 600mm
-Rolling diameter : 550mm
-Printing perimeter : 175-320mm
-Alignment accuracy : ±0. 1mm
-The dimension : 2000×1500×3000mm
-Weight machines : About 2000kg
-Power: 380v/ACThree Phase （Three-phase）50H
-Total power: 6. 8kw(Free UV)
| Place of Origin: | Zhejiang in China |
| Model No: | RY-320 |
| Payment Terms: | L/C, |
| Minimum Order: | Piece/Pieces 1 |
| Supply Ability: | Piece/Pieces|8|Year |
| Delivery Time: | 30 days |
