1. Model: DC-G1290 laser cutting machine
2. Applicable Materials
Cloth, leather, wool, acrylic, plexiglass, wooden product, plastic, rubber, crystal, ceramic tile, bamboo product, jade, granite, marble, resin and other non-metal materials.
3. Applicable Industry
Processing industries of large-scale engraving and cutting, such as garment, leather, clipping, cutting of template, printing, advertisement decoration, building upholster, art gift, computerized embroidery, package, paper product , acrylic product, middle density board etc. Nonmetal sheet precision cutting and other industries.
4. Technical Parameters
Laser Power 80W
Supply Voltage 220V
Max width 1200mmx900mm
Engraving/Cutting speed 1000mm/s
Locating Precision ＜0. 01mm
Min shaping character Character: 3×3mm Letter: :2×2mm
Operating temperature 5°C -26°C
Resolution 0. 015mm
Control Configuration DSP
Data transfer Interface USB
System Environment WINDOWS2000/ WINDOWS XP
Cooling Way Water Cooling and Protection System
Graphic file format BMP, GIF, PCX, TGA, PLT, CDR, DXF, AI
Cutting thickness 0 – 20mm
Color Separation Yes
Cuts off the water supply the protection Yes
Slope Engraving Yes, 360° slope can be designed easily
Net Weight 200kg
Machine dimension 1700x1200x1150(mm)
| Place of Origin: | Shandong in China |
| Model No: | DC-G1290 |
| Brand Name: | shenhui |
| Payment Terms: | L/C,T/T(Bank Transfer), |
| Minimum Order: | Set/Sets 1 |
| Supply Ability: | Set/Sets|100|Month |
| Package: | wood box |
| Delivery Time: | 7 days |
