HPS & MH 70W Street Light (MH-150W-LNN)

Detailed Product Description

Model number	MH-150W-LNN
	Ventilation: Full-potted, no fan
Specification	Parameters
Strike voltage	3.5~5kV
Required lamp voltage	85~130V
Voltage input range	108Vac~305Vac
Rating V. In	120/277Vac
Input frequency	50Hz~60Hz
Power factor	＞0.99
Efficiency	93 %( Max)
THD	＜10%
Output power	150W
Current crest factor	＜1.5
Output frequency	approx. 170 Hz
Protection of short circuit	Yes
Protection of open circuit	Yes
Protection of ignition failure	Yes
Protection of thermal	Yes
Protection of end of lamp life (EOL)	Yes
Weight	1kg/2.2lb
Max. Lamp distance from ballast	15m/49ft
Operating temperature range	-30℃~+50℃
Dimension (L X W X H)	205X91X38 (mm)/8.077X3.583X1.496 (inch)
Max case temperature (T C)	90℃
Safety and regulation	IEC61347
EMC	EN55015
