Laser cutting Engraving Machine

Detailed Product Description

pleae write your eamil ID in you inquiry . thank you very much，or we can not contact you .

1.DC-G350A /BLaser Engraving Machine

Appl icable materials >

plastic, jade, crystal, rubber, plexiglass and other non-metal materials.

Applicable industry >

Mainly used for the engraving and cutting of little artistic works.such as engraved portraits,badges,breast cards and various engraved packages etc..

Technical parameters >

Laser power :	50W(optional)
Laser type:	Hermetic CO2 glass tube
Power supply:	AC220±10%50 HZ/AC110±10%50 HZ
Working area:	500mmx300mm
Max moving speed:	300mm/s
Worktable:	fixed table(A)/up and down(B)
Locating precision:	<0.01mm
Min shaping character:	Character:2x2mm,letter:1x1mm
Operating temperature:	5^oC-35^oC
Data transfer interface:	LPT
System environment:	WINDOWS 2000/WINDOWS XP
Cooling way:	Water cooling and protection system
Graphic format supported:	BMP,PLT,AI
Cutting thickness	0-10mm(depends on different material)
Cuts off the water supply the protection	yes
packing	Plywood case
Optional parts	irregular rotary attachment red dot

2.DC-G350C/D Laser Engraving Machine

1.DC-G350C laser engraving machine(fixed working table)

2.DC-G350D laser engraving machineup and down working table

DC-G3050 laser engraving cutting machine is a simple and useful laser processing device which is developed for the requirement of advertisements, gift packaging and other relevant fields.

1.Applicable materials >

plastic, wood, jade, crystal, rubber, plexiglass and other non-metal materials.

2.Applicable industry >

Mainly used for the engraving and cutting of little artistic works.such as engraved portraits,
badges,breast cards and various engraved packages etc..

3.Technical parameters >

Laser power :	50W(optional)
Laser type:	Hermetic CO2 glass tube
Power supply:	AC220±10% 50 HZ/AC110±10% 50 HZ
Working area:	500mmx300mm
Max moving speed:	1500mm/s
Worktable:	fixed table-DC-G350C/Up & down table-DC-G350D
Locating precision:	<0.01mm
Min shaping character:	Character:2x2mm,letter:1x1mm
Operating temperature:	5^oC-35^oC
Resolution ratio:	4500dpi
Control configuration:	DSP
Data transfer interface:	USB(offline)
System environment:	WINDOWS 2000/WINDOWS XP
Cooling way:	Water cooling and protection system
Graphic format supported:	The file which CoreDraw,Photoshop,AutoCAD can dentify(BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG, DXP,PAT,CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG, SVGZ,PCT,FMV,GEM,CMX)
Compatible software	CorelDraw,AutoCAD
Cutting thickness	0-10mm(depends on different material)
Color separation	Separation of cutting up to 256 colors
Sloping engraving	Yes,slope can be designed discretiarily
Cuts off the water supply the protection	yes
Machine dimention	1770x1200x1150(mm)
Net weight	65kg
packing	Plywood case
Optional parts	High-grade cooling system/ general cooling system imported focus lens and laser tube cylinder rotary ttachment irregular rotary attachment

Place of Origin:	Shandong in China
Model No:	DCG310
Brand Name:	Shenhui
Payment Terms:	L/C,T/T(Bank Transfer),D/P,
Minimum Order:	Set/Sets 1
Supply Ability:	Set/Sets\|25\|Month
Package:	packing information: specially make the woodcase to pack the machine .we infill the wooden case wi
Delivery Time:	7 days after downpayments
