Drainpipe Steel Mold

Detailed Product Description

I Introduction

This machine is professional used for concrete drainpipes making. It can be divided into the centrifuge mould and the drainage pipes hanging steel roller mould.

It is designed according to China Standard. The production technology is advanced, safe, reliable, and easy disassembly.

II Features

1) Designing reasonable;

2) Structure firm;

3) Nice rigidity, high precision;

4) Smooth internal wall;

5) Easy operation.

III Technical Data

1) Self-stressed mould

	GMZ103	GMZ153	GMZ203	GMZ253	GMZ304	GMZ354	GMZ404	GMZ504	GMZ604	GMZ804
Nominal diameter Do	100	150	200	250	300	350	400	500	600	800
Nominal length Lo	3000				4000
Wheel diameter D	600			960				1280		1640
Flange distance S	2370				3120

2) Three stages of Pre-stressed pipe mould

	405	505	605	705	805	905	1005	1205	1405	1605
Nominal diameter Do	400	500	600	700	800	900	1000	1200	1400	1600
Nominal length Lo	5000
Wheel diameter D	1020	1140	1300	1480	1640	1710	1820	2060	2270	2550
Flange distance S	4020
Length	5140			5160			5180		5220

IV Working Principle

1) This steel mould is working together with the drainpipe spinning machine.

2) Under the centrifugal force, the slurry in the mould is rotated with high speed, and each component is separated and released under the centrifugal force.

3) In this process, the redundant water in the concrete is released by the force of centrifugal, and the concrete is dense and high strength.
