| Hardware |
CPU |
DSP + MCU |
| OS |
Built-in OS |
| Video |
Compression format |
Motion-JPEG-N |
| Signal system |
CMOS 300,000 pixel |
| frame ratio |
25fps |
| Resolution |
VGA(640*480), CIF(320*240) |
| picture adjust |
brightness, contrast, chroma, saturation |
| Minimum illumination |
0.1 Lux/F1.2 |
| S/N ratio |
>48DB (AGC off) |
| shutter speed |
1/50s(1/60s）-1/100，000s |
| white balance |
auto |
| backlight balance |
auto |
| |
night vision |
Φ8mm * 11 LED IR 20m |
| Lens |
standard |
F1.2/6mm 54° CS |
| selected |
F1.2 3.6mm 4mm 8mm 54°CS |
| Audio |
processor |
no |
| Audio gain |
no |
| Pan/Tilt |
control |
Built-in RS485Pan horizontal rotation:0-270,Tilt vertical rotation：0-90. |
| Network |
Internet interface |
RJ-45 10/100MB ethernet network |
| Protocol |
TCP/IP,HTTP,ICMP,DHCP,FTP,SMTP,PPPoE and so on |
| Wireless |
no |
| IP mode |
Dynamic IP address,Static IP address,PPPOE |
| Delay time |
less than 500 MSEL(0.50 second) in Lan |
| Others |
shape |
ceiling,dome,indoor use |
| power |
DC12V 1A |
| Temperature |
-10~50 °C |
| Humidity |
95% RH |
| size |
net：91mm x 103mm x 135mm
gross：170mm x 170mm x 170mm |
| weight |
net：350g gross：650g |
| Attachment |
Adaptor, Disc, Manual, bracket |
| Alarm |
Input / Output |
1/1 |
| Intelligent Motion detection |
Motion Detection setting |
| Alarm action |
support email,notes alarm |
| System |
System requirement |
Microsoft Win98 SE/ME/2000/XP, Internet Explorer 5.0, NET4.5 and above |
| Features |
Safety Settings |
Supports the two-level password: administrator authority, user authority |
| Dynamic ip address |
Free bundled Dynamic Domain Name,need not register |
| superiority |
2P2 technology,have no restrict on observe numbers |
| Center management software |
1,4,9,16,25,36,64 monitor pictures in one screen of client software,remote Access by Mobile. |
| Certification |
ISO CCC FCC CE |
