| Specifications: |
| . Nominal power: 54W |
| . Actual peak output power: 60W |
| . Nominal current: 3. 6A |
| . Nominal voltage: 15V |
| . Open voltage: 20V |
| . Unfolding dimension: 1518*787mm |
| . Folding dimension: 400*280*60mm |
| . Weight: 2. 9kgs |
| Certificate: |
| CE & FCC; |
| Accessories: |
| NIL |
| Output: |
| Y connector(male & female combined connector) |
| Available product backing colors: |
| Blue, army green or jungle woodland camouflage; |
| Characters and advantages: |
| . Made by high-efficiency of thin film & flexible amorphous silicon cells; |
| . 3-layer P-N conjunction of silicon cell processing technology and thus can absorb more sunlights(red, blue & green spectrum) than |
| crystalline silicon cells(only visible & low frequency of red spectrum could be absorbed); |
| . The special self-owned patent technology of lamination polymer minimize the specular reflection of lights and thus more lights could |
| be absorbed; |
| . The special self-owned patent technology of lamination polymer minimize the lights-induced degradation & maximize its life time; |
| . With canvas cloth substrate; |
| . Flexible, lightweight, small cubage, water-proof, anti-corrosion, no glass/no brokeable, anti-UV & very endurable; |
| . Shadow tolerance and anti-tropical island effect that make sure it always could get high output power even parts in shadow or be covered; |
| . When the total weather condition is good enough, it could be with 15%-20% higher of power output than the mentioned nominal one; |
| . No influence with the temperature; |
| . Very suitable on those areas with less sunlights, only if there is a lights even in the room, it can generate power; |
| . Lifetime: 15-20 years. |
| Applications: |
| . Due to its multi-aspects of advantages than regular glass lamination of crystalline silicon panels, this type of panels are welcome & |
| widely used by individual person such as hikers, campers, fishers, frequent trvalers and minitary party into the portable solar |
| charging/power system for a portable solar charger; |
| . This panel is suitable to charge 12V storage battery; |
| Remarks: |
| . All the nominal parameters were tested under the STC(Irradiation: 1000W/m2, Spectrum: AM1. 5 & Module temperature of 25 0C); |
| . This type of panels are mainly tailor designed & made by individual customer's requirements basing on their applications; |
| . At present, we could design and supply this type of panel basing on nominal power & voltage of 1. 5W-72W & 4. 5V-30V respectively |
