Active Solar Water Heater Systems

Detailed Product Description

A 50/50 propylene glycol and water mixture from the collectors through a coil of pipe in the solar tank, and then is pumped back through the collectors. The potable water is warmed by heat transfer through contact with the pipe. These systems are pretty much the only choice in very cold climates. When there is not enough energy for sun, an electrical or gas back up element will be automatically switched on by controller.

◆ Feature:

● Simple Installation,No Maintenance,Effective operation

● Easy Retrofitting To Existing systems

● Suitable for single and multiple solar heating Application systems,

● Preferred option for extremely cold areas and questionable water quality.

● Incoming potable water is routed to the solar storage tank

● Porcelain Enemal or SUS316 Stainless Stee Storage Tank With Electrical or gas Back Up

■ Double-walled Copper Coil heat exchangers in storage tank prevent contamination of household water.

Systems Specifications: >>>

Model	Tank Capicaty	Heat pipe or U Pipe Collector		Work Station
Model	Tank Capicaty	Φ58X1800	No.	Work Station
SHCLS150S	150L	Φ58X1800	15(1 collector for 15 tubes)	A circulating unit system that gather controller and pump station
SHCLS200S	200L	Φ58X1800	20(1 collector for 20 tubes)
SHCLS300S	300L	Φ58X1800	15X2 (2 collector for 15 tubes)
SHCLS400S	400L	Φ58X1800	20X2 (2 collector for 20 tubes)
SHCLS500S	500L	Φ58X1800	15X2+20X1 (2 collector for 15 tubes, and 1 collector for 20 tubes)

Place of Origin:	Jiangsu in China
Model No:	SHCLS series
Brand Name:	Sunhome
FOB Price:	0-999 USD shanghai
Other Price Terms:	cfr & cif;
Payment Terms:	L/C,T/T(Bank Transfer),
Package:	export standard cartons;
Delivery Time:	15days
