Polaris 150cc ATV

Detailed Product Description

Engine Type :154FMI,singal cylinder,four stroke,air cooled
Displacement (ml) :148
Bore X Stroke (mm): 54×54
Compression Ratio: 9.0:1
Max. Power (kw/r/min): 6.0/7500
Max. Torque (N.m/r/min): 9.0/5000
Max. Speed (Km/h): 60
Lubrication: press splash
Clutch Type: semi-automatic
Ignition: C.D.I
Starting System: electric start
Transmission System: chain drive

CHASSIS 　

Front Suspension: double swing arm and shock absorber,independent suspention.
Rear Suspension: singal shock absorber
Front Brake: Hydraulic disc
Rear Brake: Hydraulic disc
Stationary Brake: Hydraulic Lock
Front Tire: 205/30-10
Rear Tire: 205/30-10
Battery: 12V 4Ah

DIMENSIONS 　

L X W X H (mm): 1450×1130×1020
Seat Height (mm): 670
Wheelbase (mm): 990
Turning Radius (mm): 2250
Min. Ground Clearance (mm): 90
Max. Permissionable Weight (kg): 75
Rider Capacity: 1
Dry. Weigth (kg): 124
Engine Oil (L): 0.9
Gear Oil (L)
Fuel Tank Capacity (L): 3

Others

Packing Size (mm): 1470×850×850
Packing Weight (kg): 165
Container Loading
18units/20', 42units/40', 63units/40'HQ

Colors Available: Orange,black,red,blue
