Feature:
■ Full digital beamforming technology
■ Probe automatic identification
■ 8-Segment TGC adjustment
■ Digital encoder knobs
■ Gama correction, histogram
■ Automatic report generation
(Normal/OB)
■ Scanning angle adjustment
■ 16 Level scanning depth adjustment
■ USB 2.0 For real-time picture uploading to PC
■ Biopsy guide available
■ Back-lit keyboard
Specifications:
■ Scanning mode : Convex/Linear/Micro-convex
■ Display modes : B,B+B,B+M,M,4B
■ Scanning depth : 240mm Gray scales : 256
■ Cine-loop : 829 frames (Max)
■ Image permanent storage : 32 frames
■ Image conversion : up/down, left/right, black/white
■ Local zoom : 2 times both in real-time and frozen
■ Measurement : distance, circumference, area,
■ volume, EF rate, heart rate OB measurments : BPD, GS, CRL, FL, AD, HC,
■ AC, EDD, GA, FW Probe connector : 2
■ Probes selectable : convex, linear, micro-convex,
■ transvaginal and endorectal Ports : PAL-D,USB 2.0
■ Monitor : 12 inch SVGA
■ Body marks : 40
■ Comment : date&time, name, sex, age, doctor,
■ hospital, annotation (whole screen commentinput)
Wide application : abdominal, OB/GYN, urology,
■ cardiology, small parts examination, etc.
Standard Configuration:
■ 3.5MHz Convex
Options
■ 7.5MHz Linear
■ 5.0MHz Micro-Convex
■ 6.5MHz Transvaginal Convex
■ 7.5MHz Endorectal Linear
■ Video Printer
■ Biopsy bracket
| Place of Origin: | Hebei in China |
| Model No: | CMS 600C-3 |
| Brand Name: | CONTEC |
| Payment Terms: | T/T(Bank Transfer),Western Union,PayPal, |
