Diesel Engine

Diesel Engine

  Prev Product Contact Now Next Product

Detailed Product Description

Model
170F/FE
178F/FE
186F/FE
Type
Vertical, single cylinder,4-stroke, air-cooled
Combustion system
Direct injection
Bore × stroke [mm(in)]
70×55(2.76×2.11)
78×62(3.07×2.44)
86×70(3.39×2.76)
Displacement [L(cc)]
0.211(211)
0.296(296)
0.406(406)
Compression ratio
20:01
20:01
19:01
Rated power [KW/rpm]
2.5/3000,2.8/3600
3.7/3000,4.0/3600

5.7/3000,6.3/3600

Rated power [hp/rpm]
3.4/3000,3.8/3600
5.0/3000,5.5/3600
7.7/3000,8.6/3600
Rated speed (rpm)
3000/3600
Starting system
F: recoil starter, E: electric starter
Fuel tank capacity [L(US.gal)]
2.5(0.66)
3.5(0.92)
5.5(1.45)
Lube capacity [L(US.gal)]
0.75(0.20)
1.1(0.29)
1.65(0.44)
Fuel consumption [g(ml)/KWh]
3000rpm:280(383)
3000rpm:276(378)
3000rpm:275(376)
3600rpm:288(394)
3600rpm:285(391)
3600rpm:281(385)
Fuel
0#(summer), -10#(winter) diesel oil
Lube
SAE10W30(above CC grade)
Overall dimension [mm(in)](L×W×H)
415×385×470
(16.34×15.16×18.50)
495×485×530
(19.49×19.09×20.87)
505×470×570
(19.88×18.50×22.44)
Net weight [kg(lbs)]

Recoil starter type: 27(59.4)

Recoil starter type: 36(79.20)
Recoil starter type: 49(107.80)
Electric starter type: 33(72.60)
Electric starter type: 42(92.40)
Electric starter type: 54(118.80)
Rotation direction (view from the wheel)
Clockwise
Clockwise
Clockwise
Place of Origin:Jiangsu in China
