Image Sensor |
42S/42SN |
420 line, 0.5LUX,1/3 SONY CCD |
|
50S/50SN |
420 line, 0.5LUX,1/3 SONY Super HAD CCD |
|
52S/52SN |
420 line, 0.5LUX,1/3 SONY Super HAD CCD |
|
Infrared Light |
48 infrared lights |
|
Sensitivity |
Color: 0.3Lux, B&W: 0.01Lux, Infrared: 0 Lux |
|
Infrared Wave Length |
900mm |
|
Video Compression |
H.264 Baseline Profile@Level 2.2 |
|
Video Definition |
PAL:352*288(CIF),704*288(2CIF),704*576(D1); NTSC:352*240(CIF),704*240(2CIF),704*480(D1) |
|
Video Parameters |
Brightness,Hue,Contrast,Saturation,Image quality. |
|
Streaming Format |
Optional Video Streaming or Audio&Video composite Streaming |
|
Video Frame Rate |
PAL: 1-25frames/second NTSC:1-30frames/second |
|
Video Compression Bitrate |
16Kbit/S4Mbit/S |
|
Audio Input |
1channel,linear input |
|
Audio Compression |
G.726 |
|
Audio Output |
1channel,RCA interface,linear output |
|
Audio talk-back |
Built-in Mic |
|
Supported Protocols |
TCP, UDP, IP, HTTP, FTP, SMTP, DHCP, DNS,ARP, ICMP, POP3, NTP, IPsec, UPNP,RTP,RTCP |
|
System Interface |
10M/100M self-adapting Ethernet port, |
|
1 RS485 port (supports transparent protocols) |
|
Alarm Input |
1 channel on/off input,supporting NO(normally open) or NC(normally close) sense. |
|
Alarm Output |
1 channel on/off output,120VAC 1A/24VDC 1A |
|
Input Power Supply |
DC 12V,1A |
|
Maximum Power |
Less than 6W |
|
Operating Temperature |
-10 ~ +55 |
|
Operating Humidity |
10 ~ 85% |
|
System Requirements |
Operation System:Microsoft Windows 98/ME/2000/XP/2003 Browser:Microsoft Internet Explorer 5.x or above |
