H.264 DVR Card

Model

UV18004

Video Input

4 channels video input

BNC(Vp-p = 1.0V, 75Ω)

Audio Input

4 channels audio input

BNC(Vp-p=2.0V,SNR > 83DB,Linear Electrical Level ,1000)

Total Frames

PAL : 100 fps / NTSC : 120 fps

Compression Algorithm

Video: H.264 / Audio: G.729

Compression Resolution

CIF  352*288(PAL) / 352*240(NTSC)

Preview Resolution:

D1  704*576(PAL) / 704*480(NTSC)

Video Compression

H.264, Support CBR / VBR;

Audio Compression

G.729, Audio 8kbit/sec and PCM 64kbit/sec

Alarm In/Out

Support

PTZ

Support

Motion Detection

Motion Area and sensitivity adjustable

Other functions

Watchdog / Dual Stream

Power Consumption

Less than 22W

Working Temperature

-10°C--+50°C

Working Humidity

10%--90%

Dimension

132mm×86.2mm

Weight

85g

Interface

PCI

System Requirements

OS : Windows 2000/XP/Server 2003/Vista

CPU : Intel Series

Mothercard: based on Intel 845/865/915/925/945 Chipset

Memory: 512MB or above

Display Adapter: Nvidia Geforce Mx400/440/4000 series,

FX 5200/5600 GeForce 6600

ATI Radeon 9550/9600 serials,

ATI X300/X550/X700/X1600

Intel 845G/865G/915G/945G integrated Graphics Controller
