Waterproof IP Camera

Product

UV Series IP Camera

Model

UV-IP180

UV-IP181

UV-IP182

CCD

Image Sensor

1/3 SONY 420TVL

1/3 SHARP 420TVL

1/3 SONY 480TVL

S/ N Ratio

>48db (AGC OFF)

Min Illumination

0.5 Lux

Lens Interface

CS/ C

White Balance

Auto

BLC

Auto

 IR Distance

100 Meters (16 PCS High-Power IR LED )

Feature

D1 Resolution Image, Remote/ Local Monitoring and Recording, Snapshot, OSD, Multi-recording method, Optimal Audio/ Video Synchronization.

View by IE and Client software

Software Management

64 pictures of client software. Search and distribute IP address

Security

3 Levels: administrator, user and guest.

Alarm/ Recording

Motion detection, Email when alarm ,Mobile Phone Surveillance

Schedul, Manual, Alarm Recording

Pan/Tilt Control

RS485

Browser

Windows XP/Vista Version

IE6.0 Version above

NET4.5 Version above

Hardware

CPU

32Bit RSIC Embedded Processor

OS

Embedded Linux system

Network

Protocol

TCP/IP, HTTP, ARP, RARP, TCP, ICMP, DHCP, PPPOE, DDNS, SMTP etc.

Interface

RJ45  10/ 100M Ethernet

Video

Compression

MPEG-4

Frame Rate

10-30fps (D1)

Resolution

D1: 720×576  CIF: 320×288  FIELD: 720×288  QCIF: 192×144

Input

1Ch

Output

1Ch

Audio

Compression

ADPCM

Input

Built-in MIC

Power

DC12V   1A

           Dimension

240*122*118 (mm)

              Weight

2.18 KG
