Weatherproof Cameras

Weatherproof cameras with super high speed HITACHI 14BIT DSP image processing technology and SONY high sensitivity CCD photo-electric sensor. It transmits stable quality video with high resolution and low light, suitable for Day/Night surveillance. Fashion professional enclosure is made of aluminum alloy with IP 66 waterproof standard. It can work well in a very hot environment. The highest operating temperature is 50℃. Horizontal glass diamond coating keeps it from rains. It has a ventilation system, integrated bracket and is easy to install.

Feature

·	Star Light Sensitivity: 0.05 LUX
·	OSD Menu with Various Functions
·	Digital Noise Reduction Processing
·	High Resolution, Color 540TVL
·	Flicker Prevention and Power Sync Design
·	DC12V/AC24V
·	Built-in 5-50mm Japan VF LENS
·	IP66 Standard Moisture Protection, Dust Prevention, Self-cleaning Design
·	IR Range: up to 100m optional
·	Working Temperature under -30 degrees optional

Model NO	UV-220/T	UV-221/(B)/T	UV-225/T	UV-223/T	UV-2261/T
Sensor	HITACHI High Definition	1/3" Sony (Korea DSP CCD)	SONY Wide Dynamic	20X Zoom	23X Zoom
Resolution	540TVL	450TVL	/	540TVL	500TVL
Video Format	PAL / NTSC
S/N Ratio	≥60dB		64dB	≥60dB
Mini Illumination	0.05Lux
Mirror	Vertical,Horizontal,Rotation
Electronic Amplification	NO
Imge Adjustment	YES
Colour/Black	YES
Motion Detection	YES
IR Range	100M optional
Power	DC12V/AC24V
Lens	5-50mm(Auto Lens)
Operating Environment	-10℃ ～ 50℃;Suffix+T : Operating Tem:-30℃ ～ 50℃; (Optional)
Dimension	395mm*245mm*145mm
Weight	2600g
Waterproof Level	IP-66
