Detailed Product Description
●1/3"Sony High Resolution CCD
●IR CUT Filter Removable (ICR)
●520TV line(Enhanced 620TV line)
●0.001(B/W)
●Electrical IRIS
●High Speed White Balance Mode(1Field)
●Super Digital Noise Reduction(SDNR)
●OSD Function
●Digital Slow Shutter
●H Mirror/Flicker Less
●Audio/Video Two Channel Output
●NTSC/PAL System
Model Number HD-BQ228E-CT
Type Color / Monochrome (Day / Night)
Signal System NTSC/PAL
Filter(Crystal) ICR
Image sensor 1/3"SONY Hi-Resolution CCD
Pixel NTSC:811H×508V PAL:795H×596V
Resolution 520TV line
Mini Illumination 0.005Lux
SenseUP times NC
Vertical Frequency NTSC:59.94Hz PAL:50.00Hz
Horizontal Frequency NTSC:15.734KHz PAL:15.625KHz
Clock Frequency NTSC:28.636MHz PAL:28.375MHz
Scanning System 2:1 Interlace
Sync System Internal
S/N Ratio (AGC OFF) 50db
Electronic Shutter Normal
Lens Driver DC Driver/AES
White Balance OSD Function
BLC OSD Function
Mirror OSD Function
Gain Control OSD Function
Gamma 0.45
Video Output 1V p-p,75Ω
Audio Output 2V p-p,75Ω
Power Supply DC12V / AC24V
Current Consumption 300mA
Dimension 18×13×10cm
Weight 420g
Storage Temperature -30～+60℃
Operating Temperature -10～+45℃
| Place of Origin: | Shenzhen in China |
| Model No: | HD-BQ228E-CT |
| Brand Name: | HDD |
