KT836 Technical parameter
Bucket capacity 1.7m3
Rated load 3t
Operating Weight 9.6t
Max. Digging force 100KN
Max. Pull 90KN
Max. Climbing gradient ≥25o
Lift time of bucket ≤6S
Total cycling times ≤10.5S
Overall Dimensions
Length x width x height(mm) 6955 x 2400 x 3180
Tread width 1800mm
Wheelbase 2850mm
Max. Dumping height ≥2990mm
Max. Dumping reach ≥950mm
Engine WEICHAI DEUTZ
Model TD226B-6G
Style In-line arrangement,water-cool,four-stroke,direct injection
Aspiration Turbocharger
Max. Torque 500/1450NM/r/min
Rated power 92KW
Rated speed 2200r/min
Min.Specific fuel consumption 226g/kw.H
Transmission agent
Torque converter style YJSW315-3A
Style Two-turbofan single stagebiphase four-element
Gear-box style ZL40.50
Style Satellite gear power shift
Number of speed threshold (forward/backward) 2/1
Max.Vehicle speed 36km/h
Fore-and-aft driving axle
Main transmission style Single stage screw bevel gear reducer
Hub reduction style Single stage satellite gear reducer
Tyre size 17.5-25(12)PR
Steering system
Style Hinge joint fluid-link steering
Full hydraulic pressure sensing redirector BZZ5-E500C
Priority flow metering valve YXL-F250L-N7
Steering pump CBGq2080
Steering angle ±35o
Min. Radius (outside bucket) ≤6170mm
Hydraulic circuit
Multichannel conversion valve DF32.2C
Braking system
Service brake Gas-cap reservoir four turntable brake
Parking brake Flexible shaft control internal expanding shoe
Capacity parameter
Fuel tankage 150L
Hydraulic fluid chamber tankage 150L
Remarks: Due to innovation, technical parameter subject to change without notice
| Place of Origin: | Fujian in China |
| Model No: | KT836 |
| Brand Name: | Ken Tak |
