Go Kart (YG-150FS)

YG-150FS

1) Engine type: 150cc,single cylinder,4 stroke, Air cooling,
 Automatic with reverse
 Rating Power: 6.5kw/7500rpm
 Max torque: 9.0N.m/5500rpm
 2) Transmission mode: Chain  drive
 3) Gas tank capacity/Fuel: 6 L/Unleaded gasoline above No.90
 4) Start way: Electric start
 5) Battery: 12V.9Ah
 6) Max. speed : 60  km/h
 7) Wheel bases: 1610mm
 8) Distance between wheel:
                    Front: 1190 mm
                     Rear: 960 mm
 9) Front/Rear tire:  19x 7- 8NHS/ 22x10-11NHS
 10) Brake(front/rear): Hydraulic brake
 11) N.W./ G.W.: 243 kg/298kg
 12) Max loading capacity:  250 kg

 Overall size: 2240x1390x1440mm
 Carton size:  2300x1460x855mm
           2250x1300x650mm
 Conveyance:
          Qty/20' FCL:   9 pcs
          Qty/40' HQ:  24 pcs(with wheels)
          Qty/40' HQ:  36 pcs(take off the wheels)
