Product Features：
The use of high-strength shell of aluminum die-casting，With good heat dissipation, the characteristics of beautiful shape。American imports of light chip beads，Has a high luminous intensity, energy saving, long-life, environmental protection, job security and so on. |
|
Product use：
Landscape lighting, city lighting engineering, stage lighting, architectural lighting, advertising lighting, etc. |
|
Product Appearance Description |
1,Size |
370*245*130MM |
|
2,Material |
Die-casting aluminum shell, toughened glass |
|
3,Color |
Silvery white,Black |
|
4,Surface Treatment |
Paint |
|
5,Connector type |
DMX512 |
|
Parameters
Of
Electrical products |
1,Power |
30×1W |
|
2,LED Quantity |
30PCS |
|
3,InputVoltage |
AC100～240V |
|
4,Light-emitting angle |
15°,30°,45° |
|
5,Luminous flux of each LED
Red:40～50Lm Yellow:40～50Lm Blue:15～20Lm Green:60～70Lm
White:70～80Lm/80～90Lm/90～100Lm/100～120Lm
WarmWhite:55～65Lm/65～75Lm/75～90Lm/90～100Lm |
|
6,Lamp's Efficiency |
﹥95％ |
|
7,Color temperature
Red:620～630nm Yellow:588～593nm Blue:460～470nm Green:520～530nm
White:6000～7000K WarmWhite:2700～3300K |
|
8,Chip Voltage
Red/Yellow :2.0～2.5VDC Blue/Green/White/WarmWhite:3.0～3.6VDC |
|
9,Chip Current
Red/Yellow:400mA Blue/Green/White/WarmWhite:350mA, |
|
10,Frequency Range |
50～60Hz |
|
11,Power Factor(PF) |
﹥90％ |
|
12,Color Index(CRI) |
Ra＞80 |
|
13,Junction Temperature(Tj) |
60 ° C ± 1 0% ( Ta= 25 ° C ) |
|
14,Working Temperature工 |
- 30 ° C ~ 40 ° C |
|
15,Working Humidity工 |
10 % ~ 90 % RH |
|
16,Working Life |
30,000 Hrs |
|
17,Projection distance |
≧10M |
|
18,Control Mode |
Built-in constant current driver / control changes in full-color / DMX512 control |
|
19,Changes in the effect |
Water, RGB full color change, 256RGB gray-level |
|
20,Protection level |
IP68 |
|
Packaging |
1,White box packaging
2,White box size:
3,Weight:
4,Carton size：
5,Each containing：
6,Gross weight： |
|
Remark：
Customers can customize the package size and appearance |
