Technical Parameters Of 185W Monocrystalline Solar Modules.
Model No.: GYS-185C(185W)
Origin(Country): China
Nominal Power Pmax(W): 185W
Tolerance(%): +/-5%
Kind of Cell(Mono. Poly): Mono
Cell per Module: 72(6X12)
Conversion Efficiency: ≥17%
Shape of cell "X” mm*mm: 125*125
Main Electrical Characteristics:
Voltage Mpp Vmp[V]: 36.5V
Current Mpp Imp[A]: 5.07A
Volt Open circuit Voc (V): 43.5V
Short out current Mpp Isc [A]: 5.90A
NOCT[C]: 47℃
Max system Volt[V]: 1000V
Length[mm]: 1575
Width[mm]: 825
Thickness(without box)[mm]: 46
Weight[kg]: ~17
Packing: 2pcs in one Carton
Guarantee of power %/Years: 80% of 20 years.
Guarantee on the whole product [years]: 2 years
Kind of glass and its thickness[mm]: 3.2mm
Number of Diods: 3
Type of diods: 10A
Conditions: (STD):
Temperature Coefficient Current Isc mA/℃: +0.08%℃
Temperature Coefficient Voltage Voc mV/℃: -0.37%℃
Temperature Coefficient Power Pmax/℃: -0.44%℃
Maximum Working Temperature: + 85°C
Minimum Working Temperature: - 40°C
Remarks:
1):185w Solar Panels with IEC Certificated.
2):By Pass Diodes inside ,with TUV Certificated.
3): All the panels are made with good quality and sell at reasonable price.
| Place of Origin: | Shanghai in China |
| Model No: | GYS-185C |
| FOB Price: | 350-400 USD FOB Shanghai |
| Payment Terms: | L/C,T/T(Bank Transfer), |
| Minimum Order: | Piece/Pieces 50 |
| Supply Ability: | Piece/Pieces|200|Day |
| Package: | 2pcs in each Carton |
| Delivery Time: | within 10-15 days after the order is confirmed |
