(MR6134A)RFID UHF reader

Detailed Product Description

Reader introduce RFID Fixed reader MR 6134A

MR6134A is base on generation 1MR6034Aproduct improved generation 2 RFID reader,This reader compatible many protocolseparate type designconnect with 4 antennafast readingmulti tag identifyIndustry protection grade design etc. This reader are widely use in various RFID system,reference application as below

Reader characteristic:

Special Anti collision algorithm, high efficient of multi-tag identify capability

Four separate transmit/receive antenna to make more wide of area in the application

Compatible ISO18000-6B and ISO18000-6C(EPC-GEN2) protocol standard

Read/Write tag capabilityread 5-8m, write is 60% of read readingdepend on different tag

Reader support multi tag identifysingle tag readtag writelockand Kill tag etc.

Capability specification

Model No.	MR 6134A
Standard Compliance	ISO18000-6B,ISO18000-6CEPC GEN2
Frequency Range	Standard ISM 902928MHz or ISM 865868MHz option (other frequency depend on customer request)
Operation Mode	FHSS
RF Power	0~30dBm,software configurable
Communication Interface	Standard RS232, RJ45TCP/IP, RS485,
Output Port	4 Tem OUTPORTcan control output high/low level
Reading Range	Depends on antenna gain connect 12dBi antenna, the reading distance above 8 m
Signal	BUZZER and LED
Antenna	One ~ Four Antennas, TNC connector
Power Supply	DC9V(Supply AC/DC power adapter)
Dimension	310mm×210mm×40mm
Weight	2 Kg
Operation Temperature	20~80
