Adjustable Straight Flow Nozzle

Detailed Product Description

Feature: The adjustable perpendicular jet nozzle is widely in spray fountain of various kinds of spots, which is an indispensable nozzle for music fountain. This kind of nozzle is equipped with a spherical joint, which can be adjusted by15 degrees along the vertical direction. The adjustable perpendicular jet nozzle can produce different jetting effects by combination of various shapes. The change of height and the angle of the jet flow can be determined by the water pool size.

Model	Specification		Working pressure (Mpa)	Working water jet capacity (m³/h)	Working water jet height (m)	Water surface cover diameter (m)
Model	mm	INCN	Working pressure (Mpa)	Working water jet capacity (m³/h)	Working water jet height (m)	Water surface cover diameter (m)
RLZ-01-15	15	G1/2	0.1~0.3	0.6~1.5	0.5~2.0	0.5~2.0
RLZ-01-20	20	G3/4	0.1~0.3	2~4	1~3	0.5~2.5
RLZ-01-25	25	G1	0.3~0.5	4~8	3~8	1.0~1.5
RLZ-01-40	40	G1 1/2	0.3~0.5	10~20	8~12	1.5~2.0
RLZ-01-50	50	G2	0.5~0.7	15~30	12~15	2.0~2.5
RLZ-01-65	65	G2 1/2	0.5~0.7	40~65	15~20	2.5~3.0
RLZ-01-80	80	G3	0.6~0.8	50~80	15~30	3.0~5.0

Place of Origin:	Guangdong in China
Brand Name:	Spoondrift
Payment Terms:	L/C,T/T(Bank Transfer),Western Union,
Package:	wooden case
Delivery Time:	15 days
