Silent Diesel generator KDE6500T3 CE Approved
Model Diesel generators KDE6500T
Frequency（HZ） 50 60 Output power (kVA) 5.5 6.3 Max.
Power (kVA) 6 7
Voltage (V) 230/400 240/416
Current (A) 7.9 8.7 Rated speed (r/min) 3000 3600 Phase Three-phase Power factor 0.8(delay)
Excitation system Self-excited constant voltage(AVR)
Noise level（7m）dB（A）
Type T3: 72 Fuel tank capacity(L)
Type T3: 15 Structure
Type T3:silent Panel Ordinary Panel
Output socket One single-phase, and one three-phase
Output terminal post No DC12V output Terminal post Net weight (kg)
Type T3:170 Dimension (L*W*H)(mm)
T3:970*558*768 Engine model KA186FA Engine type Single-cylinder, vertical, four-stroke, air-cooled, direct injection Cylinder Bore Diameter X stroke(mm) 86X72 Displacement (L) 0.418 Power (kW) 5.7/3000 6.3/3600
Fuel consumption rate(g.KW/h) 275.1 281.5 Compression ratio 19 Lubrication system Pressure splash Type Engine starting system
Type T3: Electric starter Diesel oil model Summer:0#, Winter:-10# Lube oil model SAE10W-30 (above CD grade) Lube oil capacity (L) 1.65 Battery capacity (V-AH) 12V-36Ah
Portable diesel generator.Small generator.Run steadily.Small size.Light.With wheel.Easily moved.Very convenice.
Fuel-efficient Excellent performance, economic use, long service life.Light and easy to move.
Diesel generator set, Air-cooled Diesel generator set,generator,genset,generation,small generator
| Model No: | genset 6500T3 |
| keyword: | Diesel Generator Setportable diesel generatorgeneratorpower generatorgensetgensetsportable gen |
| Payment Terms: | L/C,T/T(Bank Transfer), |
| Minimum Order: | Piece/Pieces 5 |
