This machine adopts the latest technology of Tai wan computer mainboard, has Linux System and modular design .You can turn on and turn off the computer at will. With Chinese-English menu, it can show all operation interface and parameter interface of pumps, test performance of advance governor, show rack travel curve(optional), print and save debugging data of fuel injection pumps.
Characters:
1. Primary motor frequency changing speed.
2. Large output torque , small fall speed value, high precision measurement.
3. Digital display of rotation speed , counting ,temperature.
4. Automatic control of fuel temperature.
5. Ten kinds of rotation speed presetting.
6. Positive and negative system with air pressure.
7. D.C.Supply:12V/24V.
8. Protection system of over pressure, over load and over heat.
Functions:
1. Test fuel supply in every cylinder under different rotation speed.
2. Test time of fuel supply in every cylinder.
3. Test performance of mechanical speed governors.
4. Test electromagnetic valve of distributor pumps
5. Test sealing of fuel injection pump.
6. Test inner pressure and oil back pressure of distributor pumps
7. Test performance of pressure compensators.
8. Test performance of pneumatic speed governor.
9. Test negative pressure performance of pneumatic film speed governor.
| Place of Origin: | Shandong in China |
| Model No: | 12PSB-1 |
| Brand Name: | HB |
| Minimum Order: | Set/Sets 1 |
