Deutz air cooled generator

Detailed Product Description

Product description :

GENSET MODEL              AP-DE30A

                           Genset Manufacturer: ALL POWER

                           PRIME              STANDBY

GENSET OUTPUT              24KW              26.4KW

GENSET OUTPUT              30KVA             33KVA

SHORT CIRCUIT PROTECTION   MCCB

VOLTAGE/FREQUENCY/POWER FACTOR  400V/230V,50Hz,0.8lag, 3 Phase and 4 Wires

RELATIVE VOLTAGE ADJUST RANGE   0~5%

MOMENT VOLTAGE ADJUST RATIO -15%~+20%

STEADY FREQUENCY ADJUST RATIO   0~5%

MOMENT FREQUENCY ADJUST RATIO   -7%~+10%

FREQUENCY FLUCTUATION RATIO 0.5%

DIESEL ENGINE MODEL      F4L912D

ENGINE MANUFACTURER        China Deutz

ENGINE OUTPUT (KW)         32

ENGINE CONFIGURATION       Air-cooled, 4L, 4-cycle, Direct Injection

ASPIRATION                 Naturally Aspirtae

BORE(MM)*TROKE(MM)       100X120

DISPLACEMENT(L)            3.8

SPEEDING (R/MIN)           1500

START MODEL                ELECTRIC MOTOR START

SPEED GOVERNOR             Mechanical/ Electrical

FUEL CONSUMPTION (G/KW.H)   228

LUB-OIL CAPACITY(L)        12

ALTERNATOR MODEL         MEGATON MWL345 23GA1

ALTERNATOR MANUFACTURER    SHANGHAI MEGATON

TYPE                       3 PHASE AND 4 WIRES,BRUSHLESS EXCITATION,SELF REGULATING VOLTAGE

INSULATION CLASS           H

DIMENSION(MM)              1850*820*1200

Net Weight(KG)             975
