Manual KVM switch (PS/2)
Support Microsoft Intelimouse, Logitech Net Mouse, etc
Support DOS, win3. X, Win95/98/98SE/2000/ME/XP, WinNT,
Netware, Unix, Linux
Very High Video Quality-Up To 1920-1440
Bandwidth: 200MHZ
No Software Required-easy PC selection via push Buttons
Non Power
The KVM switch draws power through the keyboard port of the corresponding coumputer.
SPECIFICATIONS:
2 PCs Port, 1 Console Port,, 2 MAX PC Connections
PC Port Connector: PS/2 Keyboard mini Din 6 pin VGA HDDB 15pin
Console Port connector: PS/2 Keyboard mini Din 6 pin
PS/2 Mouse mini Din 6 pin
PC selection: Button
Keyboard Emulation: PS2
Mouse Emulation(Console port to PC port): PS2
VGA Resolution: 1920X1440
Bandwidth: 200MHZ
Housing: Metal
Dimension(MM): 140(L)X100(W)X40(H)
