2.4GHz USB Receiver(WR-703)
Features:
-- USB 2.0 output to PC-- Supports Windows 2000/XP-- Image capture, and high speed MPEG4 real-time recording-- Support MSN Messenger & Skype-- 4 channels available to avoid possible interference
-- Small size (78 x 68 x 16 mm) and beautiful appearance
Specification:Power Supply: Provided by USB PortConsumption Current (Max.): 180mAReceiving Frequency: ISM 2,400MHz~2,483MHzInput VSWR: 2:1Demodulation Type: FMIntermediate Frequency: 480MHzFrequency Stabilization: +/- 100 ppmLocal Leakage at RF Input Terminal: <=-55 dBmReceiving Sensitivity: <= -85 dBmVideo Output Signal Impedance: 75 ohmVideo Output Signal Level: 1.0 V +/- 0.15 VppVideo Output Signal Polarity: NegativeVideo S/N Ratio: 38dBAudio Output Signal Impedance: 600 ohmAudio Output Signal Level: 1.25 V +/- 0.25 Vpp / 1 kHzAudio Output Frequency Range: 250 Hz ~ 10 kHzLeft Subcarrier Frequency: 6.0 MHzUnobstructed Effective Range: 100 m (Min.)Dimensions(WxLxH): 78 x 68 x 16 mm (Excluding Antenna)Weight : 200 gOperating Temperature : -10 ~ +50 (Degree C) / +14 ~ +122 (Degree F)Storage Temperature: -20 ~ +85 (Degree C) / -4 ~ +185 (Degree F)Operating Humidity: 85% RH
