Product Parameters:
1. Model number: WJ-MCT10-60-174
2. Product size: ∮30mm, L600mm
3. Power: 8W
4. LED quantity: 174pcs
5. Illumination color: white
6. Color temperature: 3000°K-7500°K
7. Color rendering index (Ra): ≥81
8. Luminous flux: 821 lm
9. LED view angle: 120°
10. Lifespan: >40000 Hrs
11. Tube material: PC tube(transparent PC, translucence PC, transparent stripe PC, anti-glare PC), glass tube
12. Tube base material: aluminum, plastic, PC groove
13. Packing details: six pieces to one box with double deck EPE and cover, size 67x17x11cm, weight 2kgs; six boxes to one carton, size 69x56x26cm, weight 13kgs
Technical specifications:
1. Working temperature: -40℃~~+40℃
2. Adapt humidity: ≤95%
3. API: 51-100
4. EMC: ≤120dBuv
5. Input Voltage: AC85-125V, AC165-245V
6. Input current: 0.04A
7. Output Voltage: DC50-150V
8. Working frequency: 50-60HZ
9. Thermal shutdown Hysteresis: 75℃
10. 2m Luminance: Left 2m: 21.5 lux, Left 1m: 42.4 lux, Middle: 60 lux, Right 1m: 42 lux, Right 2m: 22.7 lux
LED light source parameter:
1. Model: WJ-5H2UWC
2. Chip: 17um
3. LED Luminous flux: 5.5lm
4. LED Voltage: 3.0-3.3V
5. LED View angle: 120°
Application: indoor and outdoor lighting, supermarket, residential areas, underwater lighting, garden and plant growning lighting, displaying purpose
Note:
1. Please use correct voltage supply
2. Please read the installation carefully before using the product
| Place of Origin: | Guangdong in China |
| Payment Terms: | T/T(Bank Transfer),Western Union, |
