Scanning mode |
2D (B mode), TM (M mode), PW, CW. CFM |
|
Display mode |
single frame B/ dual-frame B/ quad-frame B, M or B+M, CFM+M, CFM+PW, 4B |
|
Monitor |
17-inch color monitor/640 x 480 pixel resolution/PAL/NTSC compatible |
|
Keyboard |
back lightening/10 software controlled function keys/tracking ball for TM, CW/PW line steering, PW gate positioning, CFM colour window resizing and position, focus point setting, annotation positioning, measurements and cine mode review/keyboard removable for cleaning operation |
|
Screen layout |
patient identification field/technical data field/measurement field/menu field/Freeze mode indicator/cine loop memory indicator/Annotation/Image orientation indicator/body mark/ECG display/biopsy channel/CFM window |
|
Routine measurement |
distance, area, perimeter, volume, proportion, angle, time interval, slope, heart rate etc. |
|
Software measurement |
heart, obstetric, gynecology, urology |
|
Handling of image |
over 4 dynamic focusing, gamma correct, pre-handling, frame correlated, line correlated, post-handling, up/below turn, left/right turn, polarity turn, depth upgrae, edge strengthen |
|
Display of characters |
date, time, patient data, doctor name and hospital data input, probe frequency and mark, body mark, image depth, frame frequency, magnification, calculating value, full screen characters editing, image character annotation, etc. |
|
Puncturing guide |
can prove the position of puncturing thread |
|
Magnification |
part magnification function |
|
Probe connectors |
3 |
|
Power supply |
AC 160V~260V, 50Hz±2% |
