DESCRIPTION The series of MR600 RF reader make use of PHILIPS's SL RC400; MF RC500; MF RC531 and CL RC632 for PCD, Its can read and writecontactless cards that compliant withthe standard of ISO1443-A/B(include double interface card), RFid that compliant withthe standard of ISO15693, PHILIPS' I. Code and SAM card that compliant with the standard of ISO7816; 8 BYTES LED DISPLAY; The inside contains of CLOCK, can display the time; 512K BYTES FLASH DATE MEMORY.
OPERATE CARD TYPES
Mifare One S50, Mifare One S70, Mifare One UltraLight, Mifare Pro, 66CL160S, AT88RF020, SR176, SRIX4K（TYPE-B, TI RFid Tag-it HF-I, PHILIPS I. Code, SAM (19200BPS; 49000BPS)
TAB ILLUMINATE
.. MR6001A B(C) IT IS NOT HAVE THIS TERM WHEN THE INTERFACE FACE IS "U"
| | |
| | C: POWER
| | K: KEYBOARD GET POWER
| | U: USB GET POWER
| B: SUPPORT TYPES OF CARD:
| A: TYPE A
| B: TYPE B
| C: TYPE A+B
| D: TYPE A+CONTACT CARD
| E: TYPE B+CONTACT CARD
| F: TYPE A+B+CONTACT CARD
| G: RFid
| H: I. Code
A: INTERFACE FACE
S: RS232
U: USB
SUCH AS: MR-600SAK IS: COM, KEYBOARD GET POWER TYPE A READER
SUCH AS: MR-600SCU IS: COM, USBTYPE GET POWER TYPE A+B RADER
PARAMETER DATE MEMORY: OPTIONAL
DISTANCE: Mifare One > 100mm
BAUD RATE: 4800 ~ 115200 BPS
USB PROTOCOL: 1. 1
POWER : DC5V + 10%
MAX CONSUMPTION: 1. 5W
TEMPERATURE: -10 ~ +70
RELATIVE HUMIDITY: 35% ~ 95%
DIMENSION: 141 * 100* 31 (mm)
WEIGHT: ABOUT150g
ELECTRIFY CONDITION
DISPLAY CONDITION OF LED
CONDITION MEANINGS
GREEN initialization
RED initialization successful
YELLOW initialization unsuccessful
PROGRAM VB, VC++, C++ Builder, Delphi, Power Builder
DOWNLOAD
MR600SAK MR600SBK MR600SCK MR600SGK MR600SHK
---------------------------------------------------------------
Jinmuyu Electronics Co., Ltd. is a high technical supplier founded in 2003, specializing in the development, manufacture, marketing of IC cards, IC card-related equipment, system software and system integration of computer projects. Our products are widely used in the fields of finance, communications, social insurance, industrial and commercial management, taxation, enterprises and public organs, rfid reader, smart reader, smartcard reader, chip reader, proximity reader, mifare reader, ic card reader, contactless reader, proximity card reader, contactless reader, rfid card reader, uhf rfid reader, proximity readers, contactless card reader, rfid tag reader, RFID reader, RFID module, Mifare card, smart card reader, etc.
Sales Manager: Liu Haigang
Notice: please google for "jinmuyu" and you'll find our website.
| Place of Origin: | Beijing in China |
| Model No: | M600 |
| Brand Name: | JYM |
| FOB Price: | 35-40 USD Beijing |
| Payment Terms: | L/C,T/T(Bank Transfer),Western Union, |
| Package: | Carton |
| Delivery Time: | Delievry in 5 days after the payment is received. |
