Detailed Product Description
FEATURES
2 adjustable white LED lighting
Lens: F2.8 view of angele 54°
1/18″analog CMOS
Focal distance:3-6cm
Lens outer diameter 10mm
NTSC TV Video output
Picture vertical mirror function
Metal tube in 1meter length(1m~20m option)
Tube outer diameter 6.8mm
2.4"Color LCD:234*320 pixels
Powered by 4 X AA batteries
PE covered tube,ABS Handler
Magnetic & Hook accessories
SPECIFICATION
Item Parameter
Sensor 1/18″analog CMOS
Array Size 320×240 (NTSC)
View angle 54°
LED 2 pcs (light adjustable)
Focal distance 3-6cm
LCD 2.4″ TFT 234×320 pixels
Video out format NTSC
Level of waterproof IP68
Outer diameter of camera 10mm
Outer diameter of tube 6.8mm
Length of metal tube 1m (1m~20m option)
Continuous working time 10h(Max)
Battery 4 X AA
Body Size(L×W×H) 81×75×62mm(Max)
Handle Size φ40×110mm(Max)
Tool Box Size 325×190×73mm(Max)
Weight TBA
Store temperature -20℃～+80℃
Operation temperature -10℃～+50℃
Operation humidity 15%～95%
| Place of Origin: | Shenzhen in China |
| Model No: | HH609 |
| FOB Price: | 118 USD shenzhen |
| Payment Terms: | T/T(Bank Transfer),Western Union, |
| Minimum Order: | Set/Sets 6 |
| Supply Ability: | Set/Sets|5000|Quarter |
| Package: | Tool Box |
