Generating Set

Detailed Product Description

Model of Gen-set		Unit	1GF	2GF	3GF	5GF	8GF	10GF	12GF
Rated power		KW	1	2	3	5	8	10	12
Diesel Engine	Model		165F	170F (D)	R175 (ND)	S195 (ND)	S1100 (ND)	ZH1105 (ND) 295D	ZH1110 (ND) 295D
	12Hours Ratedoutput	kw/ps	2.21/3	2.94/4	4.4/6	8.8/12	1115	13.2/18	14.7/20
	Fuel Consumption	g/kw.h	292.3			257		246.2	248.2
	Cooling Method		air/water-cooled			evaporation or radiator
	Starting Method		hand cranking or electric starting
Generator	Model		ST-1 STC-1	ST-2 STC-2	ST-3 STC-3	ST-5 STC-5	ST-8 STC-8	ST-10 STC-10	ST-12 TFW-12
	Rated Output	KW	1	2	3	5	8	10	12
	Rated Voltage	V	230V/115V 400V/230V
	Rated Current	A	4.34 1.8	8.7 3.6	13 5.4	21.8 9	34.8 14.4	43.5 18.1	52.1 21.7
	Frequency	Hz	50/60Hz
	Power Factor		1 0.8	1 0.8	1 0.8	1 0.8	1 0.8	1 0.8	1 0.8
	Phase/ Connection		1-phase or 3-phase 4-wire
	Excitation		harmonic excitation or phase compund or brushless
Control Panel	Model								BF-S-12
Control Panel	Voltage Regulation		manual or automatic
Net Weight		kg	90	130	150	320	340	360	380
Net Weight		kg	110	150	170	360	380	400	420
Packing Size L x W x H		cm	100x52x65			135x71x76		140x71x76
