Fly Board

Detailed Product Description

Fly board flexible led display

Main features:

1. Full-color LED panel Fly board is made with SMD LEDs and high-quality fire-proofing ABS material. The panel is 288mm square, weight only one kilogram, and contain 256 pixels on a 18mm pitch.

2. It is very popular for its small-size, light-weight, transparency and convenience in setting-up. The lightweight, transparent LED System is comprised of module panels, power supply box, data distribution, rigging hardware etc.

3. The module panels can be fan-folded into and out of flight case. You can set up the panels into different shapes as you like, also you can fold the group of panels into circle or arch if needed.

4. Four different colors for the frame can be selectable. They are white, black, blue and orange. Fly Board panels are mostly used in indoor shows, exhibitions, concerts, advertisements etc.

Specification:

Product Code	LF008-029-01	Weight (kg)	1kg
Pixel Pitch	18mm	Scan Method	Static Status
Pixel Configuration	SMD 5050	Grey Scale	256 grade each R\G\B
Size of Each Screen	288×288（mm）	Display Color	16777216
Pixel/Screen	16×16(L×W)	Refresh Frame Speed	≥60（Frame /Second）
Density (Pixel / m²)	3086	Control Method	With computer monitor in phase
Angle of View	Level /Uprightness 140°	Display Mode	1024×768 Or 800×600
Luminance	3700（cd/ m²）	Life -span	≥50000h
Discernible Visual Distance	≥10-100 m	Working Voltage	DC-48V
Color Temperature	6500～9500K	Control Distance	<100m（no relay）
Power of Peak Value	80 W	Surroundings Temperature	-10℃～50℃
Average Power	60 W	Surroundings Humidity	10％～90％RH
Certificate	CE ,ROSH	Protective Rate	IP40

Place of Origin:	Guangdong in China
Model No:	Fly board
Brand Name:	ABOUTSHOW
Package:	Flight case or wood case
