CNC Drilling Machine (K45MT/1325)

CNC Drilling Machine (K45MT/1325)

Contact Now

Detailed Product Description

K45MT/1325 Series

Technical Parameter:

Model	K45MT/1325
X-Y-Z axis working area	1,300 x 2,550 x 200mm
Machine size	2,150 x 3,150mm
Resolutions	0.025mm
X-Y movement	Rack and pinion, gear drive/Taiwan
Z movement	Ball screw drive/Germany
Guide	Linear ￠20 square/Taiwan
Max. speed	35,000mm/min
Max. cutting speed	25,000mm/min
Spindle	4.5kw
Spindle speed	24,000rpm
Inverter power	7.5kw
Drive motors	stepper
Working voltage	AC380V/50-60Hz, 3-phase
Command code	G code
Computer interface	USB 2.2
Collet	ER25-12.7mm,6mm,3.175mm
Software	Type3 Software/France
Controls	DSP0501 (Digital Signal Processor)
Packing dimensions	2260 x 3250 x 1960 mm,1450 kgs
Equipment available	a.Vacuum hold down b.Auto cut adjusting device c.Oil lubrication system d.Clamps and vacuum fitting

Place of Origin:	Shandong in China
Model No:	K45MT/1325
Brand Name:	quick cnc
Payment Terms:	L/C,T/T(Bank Transfer),
Minimum Order:	Set/Sets 1
Supply Ability:	Set/Sets\|200\|Month
Package:	plywood
Delivery Time:	15 days
