Miniature Circuit Breaker

High breaking capacity Circuit Breaker DZ47-100 has advanced structure, reliable performance, high breaking capacity, novel shell etc. Its made up of shell and anti-impact high flame-retardant materials. Its applicable for the electric system of AC50Hz/60Hz, rated voltage up to 400V, rated current 100A and below. Its used mainly for the lighting, power distribution circuit and over-load of the equipment, short-circuit protection of the office, dwelling house etc. The produt according with IEC60947 and GB14048 standard can be frequent exchanged for the circuit in the normal state.
(1)Main technical parameter:
1.Rated current of the frame(Inm)A:
63,80,100A
2.Pole NO.:1P,2P,3P,4P
3.Rated voltage(Ue)V:230/400V
4.Rated breaking capacity of short circuit:6000/Prospective current of the test circuit,
Frequency factor:0.45/0.50
Note: 1. Machine life: no less than 20,000 times make-break operation.

2. Anti hot and humid: Class 2( temperature 55 and relative humid 95)

3. The wire line can connected with terminals with clip and the fixed cable up to 25mm2 .

Place of Origin:	Zhejiang in China
Model No:	DZ47-100H
Brand Name:	YUYE
Payment Terms:	L/C,T/T(Bank Transfer),
Package:	paper box
Delivery Time:	30 days
