Perkins 2800 & 4000 series diesel generator, Power range is from 500kVA to 2264kVA
Model & Specification:(50Hz, 1500RPM, 400/230V Adjustable, 0.8 Lagging power factor)
|
GENSET MODEL |
PRIME POWER |
STANDBY POWER |
ENGINE MODEL |
DIMENSION (LXWXH) mm |
WEIGHT (kg) |
|
KVA |
KW |
KVA |
KW |
|
HPM550 |
500 |
400 |
550 |
440 |
2506-E15TAG2 |
4000X1150X2000 |
3600 |
|
HPM625 |
562.5 |
450 |
625 |
500 |
2806C-E18TAG1 |
4200X1150X2100 |
4500 |
|
HPM700 |
650 |
520 |
700 |
560 |
2806C-E18TAG2 |
4200X1150X2100 |
4800 |
|
HPM800 |
725 |
580 |
800 |
640 |
4006-23TAG2A |
4550X1700X2200 |
5580 |
|
HPM900 |
800 |
640 |
900 |
720 |
4006-23TAG3A |
4550X1700X2200 |
6100 |
|
HPM1000 |
910 |
728 |
1000 |
800 |
4008TAG2A |
4650X1870X2450 |
7500 |
|
HPM1100 |
1000 |
800 |
1100 |
880 |
4008TAG2A |
4650X1870X2450 |
7900 |
|
HPM1375 |
1250 |
1000 |
1375 |
1100 |
4012-46TWG2A |
5230X1870X2500 |
9185 |
|
HPM1650 |
1500 |
1200 |
1650 |
1320 |
4012-46TAG2A |
5230X1870X2500 |
10500 |
|
HPM1875 |
1687.5 |
1350 |
1875 |
1500 |
4012-46TAG3A |
5230X1870X2500 |
12300 |
|
HPM2264 |
2057.5 |
1646 |
2264 |
1811 |
4016TAG2A |
6000X2300X3000 |
15500 |
Performance Feature
- Engine and alternator shall be mounted on a same frame steel skid.
- Built-in damper for anti-vibration.
- Small size, low weight, easy to operating, installation and maintenance.
- World most famous brand diesel engine. UK Original Perkins Engine
- World famous brand AC alternator: Stamford, Marathon, Leroy Somer, MVC.
- Advanced and reliable control module: Key start, Auto start, Remote control by PC with RS232/485
- Full range protect function and alarm shutdown feature.
Alternator Feature
- Brush-less, 4 poles, rotation magnet.
- IP21-23(NEMA1) enclosure is standard for all industrial alternators.
- The insulation system is Class H
- Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts.
- Wide range of flange adaptors and single bearing disc coupling.
- Standard 2/3 pitch windings avoid excessive neutral currents
- AVR auto voltage regulator, auto exciter, auto adjustment
Standard Accessory
Common steel base frame, Circuit breaker, Damper, Exhaust silencer, Flexible pipe, Battery and connecting wires, Operation manual and document.
Optional Accessory
Engine coolant and oil heater, Alternator space heater, Cooling for heat exchanger, Control system with RS232/485 communication interface, Battery charger by main supply, Fuel-water separator, Daily fuel tank, ATS & paralleling system, Soundproof Canopy and Moving Trailer.
