12V 7A Waterproof LED driver for LED strip light FY1207000
| Supply Ability: | 200,000 Piece/Pieces per Month |
|---|---|
| Shipping: | FOB shenzhen, lead time:15-20 days |
| Payment Terms: | T/T, Paypal, Western Union |
-
ECVV Safebuy Services
According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
-
Safebuy Service Guarantee
Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.
Related products from verified members
| Export Markets: | North America, Eastern Europe, Southeast Asia, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | 20pcs/ctn |
Specifications
12V 7A Waterproof LED driver for LED strip light FY1207000
| Specifications: | ||||||
| Input | 100~240VAC 50~60Hz | |||||
| Power factor PF≥0.94/115VAC, PF≥0.91/230VAC | ||||||
| Efficiency: 91% | ||||||
| Leakage Current ＜0.75mA | ||||||
| Output | Voltage tolerance: +/- 5% | |||||
| Current tolerance: +/- 5% | ||||||
| Output voltage and power, details please see bottom model list | ||||||
| Packing | Product Dimension | 179*71*47mm | ||||
| White Box | 1.05KG/pc | |||||
| MTBF | 495.7Khrs min. MIL-HDBK-217F (25℃) | |||||
| Safefy and EMC |
Safety standards EMC Emission EMC Immunity |
UL60950,CSA C22.2, PSE/J60950,J55022,J3000. CE/EN55022,EN61000, FCC part 15 CB/IEC60950, CCC/GB4943, C-tick/N17653, V Eup class B EK KC/K60950,K00022,K00024 RoHS:EN2002/95-EC TUVGS/EN60950,EN60335,EN61558,EN62233. |
||||
| Protection | Over Voltage | Shut down output voltage, re-power on to recover | ||||
| Over currrent | 95~110%, Constant current limit, recovers automatically after fault condition is removed | |||||
| Short Circuit | Hiccup mode, recovers automatically after fault condition is removed | |||||
| Over Temperature | Shut down output voltage, recovers automatically after temperature goes down | |||||
| Environment | Working Temp. | ~30 ℃ + 70℃ | ||||
| Working Humidity | 20%-90% RH non-condensing | |||||
| Storage Temp.Humidity | ~40 to +75℃ 10~95 RH | |||||
| Vibration | 10~500Hz, 5G 12min./1 cycle, period for 72 min, each along X.Y.Z axes | |||||
