Mini Quad

Detailed Product Description

Specifications: 1) Max. load: 95kg 2) Max. speed: 40km/h 3) Engine: 49cc, single cylinder, two-stroke, air cooled 4) Tank capacity: 1L 5) Fuel / oil unleaded petrol: 25:1 2-stroke engine oil mixing 6) Starting system: manual hand pull (alloy pull starter shell) 7) Transmission system: chain drive through automatic clutch 8) Max. power: 2.5kW/8,700rpm 9) Max. torque: 3.2N.m/8,000rpm 10) Compression ratio: 7.6:1 11) Ignition mode: contactless 12) Tires: a) Front: 3.00-4 b) Rear: 3.00-4 13) Wheel rims: a) Light alloy b) Front: 4" - 51 c) Rear: 4" - 95 14) Brake: rear disc brake 15) Colors available: red, blue, yellow, black, green, orange 16) Product dimensions: 1,000 x 590 x 630mm Outer packing: Iron frame and cardboard box N.W.: 30kg G.W.: 34kg Conveyance: Qty/20 FCL: 80pcs Qty/40 FCL: 160pcs Qty/40 HQ: 192pcs

Model No:

BS-ATV01A
