Heavy Duty Vertical Hydraulic Freight Elevator for Sale

FOB Price:	3,000.00 - 9,800.00 USD/Unit
Supply Ability:	5,000 Unit(s) per Year
Shipping:	FOB Qingdao
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	solid iron case with wooden case

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 24months
Certification: CE
Weight: 5000kgs
Overall Dimensions: 3cbm
Table Size: 2000 x 5000mm
Max. Lifting Height: 6000mm
Min. Lifting Height: 500mm
Rated Loading Capacity: 2000kgs
Power: 5.0kw
Lift Drive / Actuation: Hydraulic
Lift Mechanism: Scissor Lift
Model Number: SJG2-6
Brand Name: SDLIFT
Lift Mechanism: Scissor Lift
Lift Drive / Actuation: Hydraulic
installation: underground
color: grey, orange, blue, black, etc.

Specifications

Heavy duty vertical hydraulic freight elevator for sale

Application:

- the hydraulic elevator can be used to lift car with different levels, suitable for car moving between stairs, from basement to first floor, to second floor, or to third floor.

- Operation is easy. There are 2 sets control system installed on the hydraulic elevator, 1 control box below, and 1 hand controller on safety rail that can be operated on work platform.

the frequent models we supplied for our clients:

MODEL	LOAD CAPACITY	PLATFORM SIZE	LIFT HEIGHT	PIT DEPTH	POWER
SJG2.5-3	2.5T	5.2m x 2.6m	3m	750mm	220V, 240V, 380V or 400V
SJG2-6.5	2T	5.2m x 2.8m	6.5m	800mm	220V, 240V, 380V or 400V
SJG2.5-3.5	2.5T	5.2m x 2.6m	3.5m	800mm	220V, 240V, 380V or 400V
SJG2.5-5	2.5T	5.6m x 3m	5m	800mm	220V, 240V, 380V or 400V
SJG3-2.5	3T	5m x 2.3m	2.5m	750mm	220V, 240V, 380V or 400V
SJG3-3	3T	5.2m x 2.6m	3m	800mm	220V, 240V, 380V or 400V
SJG3-3.5	3T	5.6m x 2.7m	3.5m	800mm	220V, 240V, 380V or 400V
SJG5-10	5T	4.5m x 2.5m	10m	1150mm	220V, 240V, 380V or 400V
SJG8-2.5	8T	6.5m x 4.5m	2.5m	850mm	220V, 240V, 380V or 400V
SJG12-3	12T	5.5m x 2.8m	3m	950mm	220V, 240V, 380V or 400V
SJG15-4.5	15T	8m x 2.2m	4.5m	1150mm	220V, 240V, 380V or 400V
SJG20-5	20T	6m x 3m	5m	1200mm	220V, 240V, 380V or 400V
the Hydraulic elevator can be customized as your detailed size.

Configuration:

1) Platform Material: rectangular tube + checkered iron

2) Scissor material: high strength Manganese Steel.

3) Hydraulic system: 380V/5.5Kw or as your request.

4) High Precision Hydraulic Cylinder.

5) Piston Rod: hard chromium plating surface.

6) High-pressure oil pump

7) Hydraulic oil: summer 46#, winter 32#

8) Controller: 1 control box below, 1 control panel above platform

Parts showing:

Heavy duty vertical hydraulic freight elevator for sale

Safety:

1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.

2) the safety rails to guarantee safety of the cars above the platform.

3) the limit switch system helps hydraulic elevator to stop at accurate position.

4) Electricity leakage protection device is equipped on, all electric components are CE certified.

5) All the hydraulic elevator Are passed 1.2 times loading test before leaving factory.

the workshops:

the cUstomers visiting:

the Certificates:

Heavy duty vertical hydraulic freight elevator for sale

Our services:

1) We can design the customerized hydraulic elevator as per your requirement.

2) the most suitable hydraulic elevator will be recommended to you once we got your requirement.

3) Shipment can be arranged from our port to your destination port.

4) Operation video can be sent to you if needed.

5) User-friendly English manual for machine installation using and maintenance.

6) Two year warranty for whole machine without man-made faults.

7) We will send you parts for free if there are any non-human factors faults during warranty time.

8) Supply 24-hours technical assistance by email, telephone or other communication online.

9) Engineers are available to your country if necessary.
