Hydraulic Warehouse Cargo Lift / Stationary Hydraulic Scissor Cargo Lift

FOB Price:	3,000.00 - 6,000.00 USD/Unit
Supply Ability:	2,000 Unit(s) per Year
Shipping:	FOB Qingdao
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	solid iron case with wooden case

Quick Details

After-sales Service Provided: Engineers available to service machinery overseas
Warranty: 24months
Certification: CE
Weight: 2500kgs
Overall Dimensions: 1300mm x 1000mm x 800mm
Table Size: 1300mm x 1000mm
Max. Lifting Height: 3800mm
Min. Lifting Height: 450mm
Rated Loading Capacity: 2000kgs
Power: 3.0kw
Lift Drive / Actuation: Hydraulic
Lift Mechanism: Scissor Lift
Model Number: SJG2-3.8
Brand Name: SDLIFT
Lift Mechanism: Scissor Lift
Lift Drive / Actuation: Hydraulic
installation: into pit
Certification: CE

Specifications

Hydraulic warehouse cargo lift / stationary hydraulic scissor cargo lift

Application:

·the scissor elevator can be used to lift cargo with different levels, suitable for cargo moving between stairs, from basement to first floor, or to second floor.

·Operation is easy. There are 2 sets control system installed on the scissor elevator, 1 control box below, and 1 hand controller on safety guard rail that can be operated on work platform.

Configuration:

1) Lift height: 3.8m

2) Lift loading capacity: 2T

3) Lift platform size: 2m*1.6m

4) Platform Material: rectangular tube + checkered anti-slip plate
5) Support scissors: high strength Manganese Steel.
6) Hydraulic system: 380V/5.5Kw or 220v or as your request
7) Hydraulic cylinder: High precision wear-resisting cylinders with locking device for fall protection
8) Piston Rod: hard chromium plating surface.
9) High-pressure oil pump: from Italy or Chinese famous brand.

10) Hydraulic pipe: high pressure pipe with double expanded metal protected

11) Hydraulic oil: summer 46#, winter 32#

12) Controller: 1 control box below, 1 hand controller above platform

the frequent models we supplied for our clients:

MODEL	LOAD CAPACITY	PLATFORM SIZE	LIFT HEIGHT	PIT DEPTH	POWER
SJG0.3-2	0.3T	1.5m x 1.5m	2m	400mm	220V, 240V, 380V or 400V
SJG0.5-3	0.5T	2m x 1.8m	3m	500mm	220V, 240V, 380V or 400V
SJG1-4.5	1T	2.1m x 1.5m	4.5m	650mm	220V, 240V, 380V or 400V
SJG1.5-4	1.5T	2.2m x 1.6m	4m	600mm	220V, 240V, 380V or 400V
SJG2-6.5	2T	5.2m x 2.8m	6.5m	800mm	220V, 240V, 380V or 400V
SJG2.5-3	2.5T	5.2m x 2.6m	3m	750mm	220V, 240V, 380V or 400V
SJG2.5-3.5	2.5T	5.2m x 2.6m	3.5m	800mm	220V, 240V, 380V or 400V
SJG2.5-5	2.5T	5.6m x 3m	5m	800mm	220V, 240V, 380V or 400V
SJG3-2.5	3T	5m x 2.3m	2.5m	750mm	220V, 240V, 380V or 400V
SJG3-3	3T	5.2m x 2.6m	3m	800mm	220V, 240V, 380V or 400V
SJG3-3.5	3T	5.6m x 2.7m	3.5m	800mm	220V, 240V, 380V or 400V
SJG5-10	5T	4.5m x 2.5m	10m	1150mm	220V, 240V, 380V or 400V
SJG8-2.5	8T	6.5m x 4.5m	2.5m	850mm	220V, 240V, 380V or 400V
SJG12-3	12T	5.5m x 2.8m	3m	950mm	220V, 240V, 380V or 400V
SJG15-4.5	15T	8m x 2.2m	4.5m	1150mm	220V, 240V, 380V or 400V
SJG20-5	20T	6m x 3m	5m	1200mm	220V, 240V, 380V or 400V
the Scissor elevator Can be customized as your detailed size.

Lifter parts showing:

Hydraulic warehouse cargo lift stationary hydraulic scissor cargo lift

Safety:

1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) the safety rails to guarantee safety of the goods above lift platform.
3) Equipped 4 guide rails, to ensure the scissor elevator runs more smoothly and steadily.
4) the limit switch system helps the scissor elevator to stop at accurate position.
5) Electricity leakage protection device is equipped on, all electric components are CE certified.
6) All the scissor elevator are passed 1.2 times loading test before leaving factory.

Our services:

1) We can design the customerized scissor elevator as per your requirement.

2) the most suitable scissor elevator will be recommended to you once we got your requirement.

3) Shipment can be arranged from our port to your destination port.

4) Operation video can be sent to you if needed.

5) User-friendly English manual for machine installation using and maintenance.

6) 2 year warranty for whole machine without man-made faults.

7) We will send you parts for free if there are any non-human factors faults during warranty time.

8) Supply 24-hours technical assistance by email, telephone or other communication online.

9)We could reply you in 2 hours after received your any questions even on weekend and holiday. Engineers are available to your country if necessary.
