Factory Direct Multifunctional Electric HF-103DM High Frequency Wire Saw
| Supply Ability: | 3 Set(s) per Day |
|---|---|
| Shipping: | 5-7 week days |
| Payment Terms: | T/T, Western Union |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Shaanxi in China |
| Packaging Details: | it's depends on goods |
Quick Details
- Type: Pocket Saw
- Material: Diamond
- Brand Name: OK
- cutting spee: 27m/s
- line spee: Diameter 11.5mm/11.0mm/10.5mm
- Weight: 85kg
- Dimensions: 900*550*1600mm
- Blade Length: None
- Model Number: HF-103DM
- Wire storage: 11mm
- Wire sintered: 11.5mm
- Wire brazed: 10mm
- Output: 32A 17KW 19kg/16A 9KW 15kg
- Drive wheel: 280mm
- Guide pulleys: 168mm
- Feed wire storage: Electric
- Voltage: 380V-460V(single phase is avaialable)
- Frequency: 50Hz/60Hz
- Weight: 18kg
Specifications
Wireless Remote Control
High frequency power and user-friendly
Wire
Wire storage 11m
Wire Φ, sintered 11.5mm
Wire Φ, brazed 10mm
Design
Drive wheel: Φ350mm
Guide pulleys: Φ168mm
Feed wire storage: electric
Electric motor
Water-cooled high-frequency motor
Output 32A 17kw 19kg
Output 16A 9kw 15kg
Control
Voltage 380~460V
Frequency 50Hz/60Hz
Weight 18kg
Wireless control 1.8kg
Dimensions & weight
Height 1100 /1600mm
Width 900mm
Depth 550mm
Weight 85kg
Weight without main motor 60kg
(Main motor can be disassembled and mounted quickly and easily)
