ODU5 Medical Use Laptop A/B Ophthalmic Ultrasound Scanner
| FOB Price: | 4,300.00 - 4,400.00 USD/Piece |
|---|---|
| Supply Ability: | 500 Piece(s) per Month |
| Shipping: | CARTON |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Hubei in China |
| Packaging Details: | CARTON |
Quick Details
- Model Number: ODU5
- Brand Name: Darppon
- Type: Ophthalmic Optical Equipments
- Type: Doppler Ultrasound Equipment, Ophthalmic Optical Equipments
- Model Number: ODU5
- Display: 10.4 adjustable LED screen
- eye mode: Support normal, cataract Aphak
Specifications
ODU5 Medical Use laptop A/B Ophthalmic Ultrasound Scanner
Product Description
Features of ODU-5 Ophthalmic Noiseless Ultrasound Equipment AB Scanner
Humanized Operation Design:
1. 10.4' adjustable LED screen;
2. Press one key could transport current image to PC workstation
3. Equipped with keyboard floodlight, used for dark room.
Abundant Dates Management:
1. 100 images permanent storage capacity
2. Standard workstation software, easily management and print data
1. 10.4' adjustable LED screen;
2. Press one key could transport current image to PC workstation
3. Equipped with keyboard floodlight, used for dark room.
Abundant Dates Management:
1. 100 images permanent storage capacity
2. Standard workstation software, easily management and print data
Technical Specification
Model
ODU-5 (Ophthalmic Ultrasound A/B Scanner)
A Scan
ACD, Lens, Vitreous and Axial length measurement
IOL Formulas: SRK-II,SRK-T,BINKHORST,HOLLADAY,HOFFER-Q,HAIGIS
Direct contact/immersion measurement
Support normal, cataract Aphakic and special eye mode
B Scan
High resolution and contrast B scan
8 kinds pseudo-color
Multiple electronic measurements: Distance, Area, Perimeter, Volume
8 kinds TGC adjustable
Others
Dual-mode TV output
PAL/NTSC
Power supply
Connecting with Video Recorder and ultrasonic working station
Adapter output
AC-100-240V ~, 1.2-0.6A, 50-60Hz
Main unit weight
DC 12.8V, 3.0V
Main unit size
4.5
