Shenzhen Richroc Electronic Co., Ltd.
China Manufacturer with main products: 12v Mini UPS, Mini UPS, UPS Battery, Router UPS, 12v DC UPS, Mini UPS for WiFi Router, DC Mini UPS, 5v UPS |
11th
Home
>Products Catalog > Mini UPS > Portable Economic Battery Power Supply Back Up DC 9V Mini UPS for Attendance Fingerprint Machine
Portable Economic Battery Power Supply Back Up DC 9V Mini UPS for Attendance Fingerprint Machine
| Supply Ability: | 2,000 Piece(s) per Week |
|---|---|
| Shipping: | international express,Bpost international |
| Payment Terms: | T/T, D/P, Western Union, MoneyGram |
| Export Markets: | South America, Eastern Europe, Africa, Oceania, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Guangdong in China |
| Packaging Details: | Carton Packing Size: 42*23*24 cm Qty: 44pcs/carton Weight: 9.1kg/carton |
Quick Details
- Application: Telecommunications
- Type: On-line
- Protection: Overcurrent
- Phase: Single Phase
- Brand Name: WGP
- Output Voltage: 9V
- Weight: 345g
- Model Number: UPS901B-06
- Capacity: 57.72wh 7800mAh
- Battery Type: 18650 lithium ion battery
- Input voltage: 9V 1000mA
- Color: Black
- Certification: CE FCC RoHS PSE
- Backup time: 2~8 hours
- Size: 111*60*43mm
- Material: ABS
- Ups in jack: 5.5*2.1mm
- Ups out jack: 5.5*2.5mm
Specifications
Portable economic Battery Power Supply Back Up 9V mini DC UPS for attendance fingerprint machine
Product Description
Mini DC UPS uninterruptible power supply is a standby energy storage power supply.
Used safe and environmental lithium cells, credible and stable PCB, trickle/constant-current/ constant-voltage lithium battery charging BMS.
Created by high performance and efficiency DC-DC, boosting and switching circuit. this mini UPS with perfect over-charged, over-discharged, over-current and short-circuit protection.
Features
Mini 9V1A mini DC UPS
over-charged, over-discharged
over-current and short-circuit protection
Private mode in UPS
We have our own PCBA Dept
7 years experienced R&D team
High Quality:CE,FCC,RoHs,PSE
| Item | Technical Requirements | Remark |
| Input voltage | 9V 5% | |
| Input current | 350mA + loading current | |
| Charging transfer efficiency | >=75% | |
| No load voltage range | 9.2V 5% | |
| Output current range | <=2000mA | |
| Output voltage range | 9.2V - 10% | |
| Discharging transfer efficiency | >=85% | |
| over-disharged protection (battery) | 6.0V | over-discharged release 6.3V |
| over-charged protection (battery) | 8.5V | over-charged release 8.25V |
Application
Smart 9V mini DC UPS widely use for fingerprint attendance machine, Fire safety system, security monitoring system, wireless camera, CCTV camera,personal treatment system,Door security system, personal data assistant, emergency lighting, Alarm system, personal communication systems, radio, digital cameras, camcorders, video camera, Bluetooth devices, CD players, MD players, portable DVD, MP3 players, smart cards.
Product Exhibition
Package Details:
| Mini UPS | 1 PC |
| DC cable | 1 PC |
| Manual | 1 PC |
| Neutral box | 1 PC |
Strength of Our Corp
FAQ
Q:What's the type of UPS?
A:It's a mini on-line UPS.
Q:how is it work?
A:When have Electricity,UPS act as a bridge, city power provide electric to device,at the same time,UPS is being charging.When no electricity,then UPS back up the device.
Q:how to charge the UPS?
A:Battery will only charge with power switch in the ON position.
Q:What's the backup time?how can i decide which model is suitable to my device?
A:Different capacity will have different backup time,with following information,we can choose the most suitable UPS to you:
1.What's the device you plan to use?
2.What's the working voltage and current?
3.What's your expected backup time?
Q:how can I maintain the device lifetime?
A:When stored, the UPS will self-discharge at a rate that is greatly affected by the ambient temperature. It should therefore be fully charged before being put into storage and if it is to be stored for a long period, it should be recharged periodically to prevent it from losing its original capacity.
as a guide, the UPS should not be stored for longer than the periods shown below without being recharged:
6 months at 20C
3 months at 30C
2 months at 35C
If the UPS was not used for long time, it is suggested to charge it once every 3~5months
Notice:More questions,please contact with me right now,we will choose the right model to you!
