ATV QUAD 300cc

Detailed Product Description

SPECIFICATION: Engine Type: 4-Strokes, Air Cooled, Single Cylinder, 5 Speeds and reverse gear Dimensions: L x W x H: 1900mm x 1050mm x 1160mm Transmission System: Shaft Drive Bore x Stroke (mm): 78x61.2 Piston Displacement: 292ML Maximum Power (kw/r/min): 16.8/7500 Maximum Torque (N.m. /r/min): 20/6000 Starting System: Electric/recoil backup Seat Height (mm): 830 Min Turning Radius (mm): 3000 Ground Clearance: 120mm Brake (Front/Rear): Disk/disk Tyre (Front/ Rear): 22*7-10/22*10-10 Ignition Type: C.D.I. Fuel Tank Capacity (L): 7.5 Front Suspension: Independent front suspension Rear Suspension: Swing arm Parking Brake: Mechanical Lock Battery: 12V-14Ah Max Load Capacity (kg): 175 Engine Oil Capacity (L): 1.6 Gear Oil Capacity (L): 0.27 Net Weight (kg): 220 Wheel Base: 1200mm Lubrication: Pressuring splash Compression Ration: 9.2:1 Color available: Red,Blue,Black,yellow,green,camouflage QTY/Container: 12units/20, 26units/40, 36units/40HQ Leading Time: 18 workdays

Model No:

YS-ATV10
