Topccd Industrial Co., Ltd.

China Manufacturer with main products: TFT LCD Monitors, Backup Cameras, 360 Degree Vision System, 1080P MDVR, Radar Detection System, Wireless Backup Systems, Wi-Fi System,...

Home >Products Catalog > Monitors > 7 Inch Heavy Duty Vehicle CCTV Quad Monitor from Topccd (TOP-D7001Q)

7 Inch Heavy Duty Vehicle CCTV Quad Monitor from Topccd (TOP-D7001Q)

FOB Price:	20.00 - 60.00 USD/Piece
Payment Terms:	T/T, Western Union, Other, Paypal

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Guangdong in China
Packaging Details:	White boxes or color boxes

Quick Details

Warranty: 2Years
Brand Name: TOPCCD
Combination: DVD Player,MP3 / MP4 Players,safety vision
Placement: Headrest
Screen Type: 16:9
Model Number: TOP-D7001Q
Car Make: Universal
Certification: CE,FCC
Screen size: 7-inch
Resolution: 800(W)*R.G.B*480(H)
Video Input: 4CH
Audio input: 1CH
Audio output: 1CH
Trigger control: 4CH
Voltage input: DC9V/32V

Specifications

. in car 7 inch digital quad splitter reversing monitor with touch button control and DC12V/24V
. Model: TOP-D7001Q
. Screen Size: 7-inch LED Digital Panel
. Resolution: 800(W)*R.G.B*480(H)
. Signal System: PAL / NTSC System Automatically
. Aspect Ratio: 16:9
. Brightness: LED,300cd/m2
. Contrast ratio: 500:1
. Video Source: 1Vp-p,75
. Video Inputs: 4CH
. Audio Inputs: 1CH
. Audio Output: 1CH
. Triggers: 4CH
. Viewing Angle: Hor. L(70) R(70); Ver. up(50) DOWN(70)
. OSD Menu Function: Image reversion,Color, Brightness,Contrast,Volume,Multi-languages
. Image reversion: up/Down and Left/Right
. Connectors: RCA or 4PIN optional
. Operation Mode: Key or remote control
. Casing Material: ABS
. Key color: Black rubber oil,radium carving, through blue light
. Bracket: "U" type bracket ("Duckfoot" Metal Bracket Optional)
. Operating Temperature: -10~+70 RH95% Max.
. Storage Temperature: -20~+80 RH95% Max.
. Power consumption: 5W
. Voltage Input: DC9V/32V
. Dimension: 180(L)*121(W)*23(H) mm
. Weight: about 612g
7 Inch Heavy duty vehicle CCTV Quad Monitor from Topccd TOPD7001Q
