4000w China CNC Metal Sheet Laser Cutting Machine for Steel Tube Plate Plate Processing

FOB Price:	145000.00 - 160000.00 USD/Set
Supply Ability:	12 Set(s) per Month
Shipping:	By sea
Payment Terms:	L/C, T/T

In Stock

Inquiry Now

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Shandong in China
Packaging Details:	Standard exporting package

Quick Details

Application: Laser Cutting
Certification: CE,ISO,SGS
Brand Name: PIONEER
Graphic Format Supported: DWG,DXF
Applicable Material: Metal
Laser Type: Fiber Laser
After-sales Service Provided: Engineers available to service machinery overseas
Model Number: PFG-3015D
Control Software: CypCut
Cooling Mode: Water Cooling
CNC or Not: Yes
Cutting Speed: 30m/min
Cutting Area: 1500x3000mm
Cutting Thickness: 25mm
Condition: New
Laser source: Raycus
Laser head: Raytools
Motor: Yaskawa
Positioning accuracy: 0.03mm/1000

Specifications

The series of pioneer PF-3025D laser cutting machine offers power ranges between 1000W to 10000W. One of the most efficient machine technologies for rapid sheet metal cutting which can cut the thickness for 50mm or less.
4000w China CNC Metal Sheet Laser Cutting Machine for Steel Tube Plate Plate Processing
1. Saving Material ---- CNC control, it can cut the material in different shapes, improve the utilization rate and reduce waste.
2.Easy Programme ----high accuracy, cut to shape without molding, smooth finish, eliminating the process for edge modification.
3. Save Investment for Molding ---- Laser cutting without molding, eliminating the cost for molding and repair, save time, resulting in less manufacturing cost, reduce the cost of goods sold, particularly suitable for processing parts in large-size.
4. Protecting Environment ---- working area for laser cutting is fully enclosed, low noise, is clean, safe, free of pollution, totally improve the working condition and environment.

Fiber Laser Cutting Equipment is suitable for metal cutting like Stainless Steel Sheet, Mild Steel Plate, Carbon Steel Sheet, Alloy Steel Plate, Spring steel Sheet, Iron Plate, Galvanized Iron, Galvanized Sheet, Aluminum Plate, Copper Sheet, Brass Sheet, Bronze Plate, Gold Plate, Silver Plate, Titanium Plate, Metal Sheet, Metal Plate, Tubes and Pipes, etc
Application Industries
Machines are widely used in manufacture Billboard, Advertising, Signs, Signage, Metal Letters, LED Letters, Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks & Cabinets Processing, Metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, Glasses Frame, Electronic Parts, Nameplates, etc.
Main Configuration

Laser power source	IPG/Raycus(2000w-10000w)
Laser head	Swiss Raytools/Germany Precitec
Servo motor	Japan Yaskawa
Reducer	Shimpo
Linear slider	Rexroth
Gear&Rack	YYC
Control system	CypCut
Machine bed	Heavy-duty plate steel welded machine bed
Gantry beam	Cast aluminum gantry structure
Water chiller	Tongfei
Electrical components	Schnider

Technical Parameter

laser power source range	2000w-10000w
effective cutting area for plate steel	3000mmx1500mm(can be customized)
tube cutting length	6000mm(can be customized)
Acceleration speed	2G
Positioning accuracy	±0.03mm
Repeating positioning accuracy	±0.015mm
Maximum moving speed	100m/min

The features of a laser cutting machine
1. High rigidity heavy chassis, reducing the vibration generated during the high-speed cutting process.
2.Gantry double drive structure, with imported Germany rack & gear transmission system, which improves the production efficiency.
3. High-performance cast aluminum guide rail, after infinite analysis, which accelerates the circular arc cutting speed.
4.High precision, fast speed, narrow slit, minimum heat-affected zone, smooth cut surface, and no burr.
5. The laser cutting head does not come into contact with the surface of the material and does not scratch the workpiece.
6. The slit is the narrowest, the heat-affected zone is the smallest, the local deformation of the workpiece is very small, and there is no mechanical deformation.
7. It has good processing flexibility, can process any pattern, and can cut pipes and other profiles.
8. Non-deformable cutting can be performed on materials of any hardness such as steel plates, stainless steel, aluminum alloy plates, and hard alloys.
