PDA Handheld UHF Reader QR Code Scanner Direct Thermal Printer NFC Reader 4G Android Intelligent Terminal

FOB Price:	449.00 - 620.00 USD/Piece
Supply Ability:	1,000 Piece(s) per Month
Shipping:	By express, air, or ocean transport
Payment Terms:	L/C, T/T, Western Union, MoneyGram, Paypal

In Stock

Inquiry Now

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangsu in China
Packaging Details:	Each one packed in one box, 20boxes in one carton, carton size: 60x24x34cm, GW: 20kg/carton

Quick Details

Brand Name: Koten
Screen Size: 5.5inch
Style: Handheld Computer
Operating System: Android
Products Status: Stock
Model Number: PDA5501
Weight: 0.51Kg
RAM: 2GB
ROM: 16GB

Specifications

PDA Handheld UHF Reader QR code scanner Direct Thermal Printer NFC reader 4G Android Intelligent Terminal

PDA5501

All-netcom 4G android multi-functional Intelligent terminal.

Healthcare Warehouse Meter reader Ticketing Parking Express Manufacturing Tracking

Processor	ARM Cortex A53 Quad-core 64bits 1.3GHz
O.S	Android7.0
Memory	16GB ROM+2GB RAM
Ex-Storage	MicroSD(up to64GB)
Display	5.5inch720x1280 HighREsolution
Camera	AF 8.0M Pixels with LED flashlight
Touch Panel	Industrial-grade capacitive touch panel
Keypad	2 side keys,Power key
NotifiCation	Vibrator/LED/Speaker
Battery	7.4V 2950mAh Rechargeable lithium polymer battery
Audio	Built-in Microphone/Headphone slot
Sensor	G-sensor
Power supply	Input:100-240V Output:9V DC,2A
Structural Parameters
Dimensions(LxWxD)	2108042mm
Weight	505g(Battery included)
Communication Transmission
Mobile Network	3G:WCDMA:850/900/1900/2100MHz CDMA/EVDO 800MHz GSM: 850/900/1800/1900MHz 4G:LTE-FDD:B1/B3/B7/B8/B28 LTE-TDD:B38/B39/B40/B41
Wi-Fi	IEEE 802.11 b/g/n
Bluetooth	Bluetooth 4.0
GPS	Supporting GPS/AGPS
SIM slot	2 SIM slots
Peripheral ports	1 Micro USB,1mini USB
Printer
Method	Direct Thermal
Speed	70mm/sec
Paper size	Paper width:58mm,roll Diameter:30mm
Sensor	Black mark / out of paper / overheat over-voltage protection
Medium	Thermal paper and label
Type	Text/image/barCode/QR code
Operating Environment
Develop Tools	Android SDK + JDK + Eclipse
P-Language	Java
Operating Temp.	-10°~ 50°C
Storage Temp.	-20°~ 70°C
Humidity	0 ~ 95% (Non-condensing)
Sealing	IP65
NFC/HF RFID
Protocol	ISO/IEC 14443A/B,ISO15693,ISO18092
Frequency	13.56MHz
NFC type	Type1-4Tag/Mifare/Felica
PSAM/Contact Card
PSAM	IS0/IEC 7816 1-4
Contact chip card	IS0/IEC 7816(optional)
SAM slot	2 SAM slots
Fingerprint reader(oPtional)
Method	Flat surface press to semiconductor sensor
Sensor	FPC1020
Image	242*266 pixels
Image resolution	508dpi
Storage	2000 pieces
Accessories

Rugged explosion-proof stable and reliable

Widely used in logistics Express, storage management, parking fees, administrative enforcement, product Traceability and other fields

Multifunction

Set 4G Netcom data transmission, barcode/two-dimensional code

Scanning module, built-in printer, contact and non-touch Chip card (NFC)

Read and write.

Multiple Optionsu

to meet the needs of different industries and Customers, optional fingerprint recognition, ultra-high frequency RFID, secondGeneration identity card identification, 433MHz communication module, Etc., and set aside a variety of extended communication interfaces
