Home >Products Catalog > Constant Voltage LED Driver > 100W 54V 1.85A Waterproof Strip Power Supply

100W 54V 1.85A Waterproof Strip Power Supply

FOB Price:	16.00 - 18.00 USD/Piece
Supply Ability:	20,000 Piece(s) per Month
Shipping:	shipping by sea
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram

In Stock

Inquiry Now Start Safebuy Order

ECVV Safebuy Services

According to the requirements of buyers, ECVV.com will purchase the cost-effective Chinese products for you from the well-chosen suppliers database which was accumulated in the past 10 years.Learn More>>
Safebuy Service Guarantee

Provide financial security for multinational purchaser; Determine delivery time and acceptance product according to the purchasing requirements; Arrange Chinese export declarations and international logistics; Provide unified delivery of products from different suppliers.

Related products from verified members

Product Details

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangsu in China
Packaging Details:	0.65KG/PC, 350x310x260mm, 20pcs /14.5Kg / 0.02CBM /CTN

Quick Details

Output Voltage: 54V
Input Voltage: 220V
Output Type: Single
Output Power: 51 - 100W
Brand Name: AMCFLEX
Output Current: 1.85A
Output Frequency: 47-63
Model Number: APMS-100-54
PF: >0.95
THD: <15%
Output voltage: 24V/27V/36V/48V/54V
warranty: 5 years
application: led street lights, led floodlights, spotlights, tunnel lights, fishing light

Specifications

100W 54V 185A Waterproof Strip Power Supply
Model:APMS-100-54

Technical Specs:
1.Output Parameters

Rated Output voltage: 54VDC

Rated Output Current:1.85A

Rated Output Power: 100W Max

Efficiency>91%

Line Regulation:±0.5%

Load Regulation:±1.5%

Voltage tolerance:±3%

2. Input Parameters

Rated Input voltage:200-277VAC

Input voltage range:176-305VAC, 47-63hz

Input Current Max:1.0A

Inrush Current<70A

Power Factor>0.95

THD<15%

3. Protection

Overload

Short Circuit

over voltage

over Temperature

4. Environment

Operating Temperature range:-40 to +80℃

Storage Temperature range:-45 to +80 ℃

Humidity: 1095%

Waterproof Level:IP67

5. Safety Standards

UL8750, IEC/EN61347-1,EN61347-2-13,EN62368, GB19510.1,

GB19510.14, IP67 Approved

Withstand voltage: I/P-O/P:3KV

EMI,EMS

EN55015(CISPR15), GB17743, EN61000-3-2, Class C, EN61000-4-2,

8KV air; Level 2, 4KV contact, EN61000-4-3, EN61000-4-4,

EN61000-4-5, 4KV/Line-Line 6KV/Line-Earth, EN61000-4-6

6. Others

MTBF>200Khours

Dimension:150(L)*51 (W)*38(H)mm

Packing: 0.65KG/PC, 350x310x260mm, 20pcs /14.5Kg / 0.02CBM /CTN

Model NO	Input Voltage	Output Voltage	Output current	Output Power	Efficiency	Dimension/mm
APMS-100-24	200-277Vac	24V	0-8.0A	0-96W	92%	155x51x38
APMS-100-36	200-277Vac	36V	0-2.77A	0-100W	92%	155x51x38
APMS-100-48	200-277Vac	48V	0-2.08A	0-100W	93%	155x51x38
APMS-100-54	200-277Vac	54V	0-1.85A	0-100W	94%	155x51x38
