30W 350mA 42-84VDC Street LED Driver

In Stock

Inquiry Now

Export Markets:	North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe
Place of Origin:	Jiangsu in China
Packaging Details:	0.35KG/PC,350 x 310 x 260 mm, 40pcs /15.5Kg /0.02CBM/CTN

Quick Details

Brand Name: AMCFLEX
Output Power: 30W
Input Voltage: 176-305VAC
warranty: 5years
Output Voltage: 42-84VDC
Model Number: APMS-30C-350
PF: >0.95
THD: <15%
Output current options: 350W/500mA/700mA/1050mA
warranty: 5 years
application: led street lights, led floodlights, spotlights, tunnel lights, fishing light

Product Features:

1. 176-305VAC wide input voltage range

2. Constant Current Drive Mode

3. Built in active PF function, PF>0,95

4. High working efficiency up to 90%

5. THD<15%, Flicker-Free Design

6. IP67 waterproof level with fine aluminum housing, suitable for outdoor applications

7. Class 2 Power unit

8. 4KV + 6KV Surge protection, more safety

9. 5 years warranty

Technical specs:

1	Input
NO	Item	Specs	Unit	Note
1.1	Input voltage	200-277	Vac	Typical 220Vac
1.2	Input voltage range	176-305	Vac
1.3	Input Frequency	50/60	Hz
1.4	Input Frequency Range	47-63	Hz
1.5	Max Input current	≤0.3	A	Vin=200Vac,rated load
1.6	Input inrush current	≤20	A	240Vac input,25℃ cold start
1.7	PF	≥0.95		Vin=200240Vac,rated load
1.8	THD	<15	%	Rated input voltage, Rated load

Model NO	Input Voltage	Output Voltage	Output current	Output Power	Efficiency	Dimension/mm
APMS-30C-350	200-277VAC	42-84VDC	350mA	30W	90%	104x51x28.5
APMS-30C-700	200-277VAC	21-42VDC	700mA	30W	90%	104x51x28.5
APMS-30C-1050	200-277VAC	14-28VDC	1050mA	30W	90%	104x51x28.5
